Lightweight Full Color Outdoor Advertising Led Display Billboard P6.4-12.8mm

Lightweight Full Color Outdoor Advertising Led Display Billboard P6.4-12.8mm
Lightweight Full Color Outdoor Advertising Led Display Billboard P6.4-12.8mm Lightweight Full Color Outdoor Advertising Led Display Billboard P6.4-12.8mm Lightweight Full Color Outdoor Advertising Led Display Billboard P6.4-12.8mm

Large Image :  Lightweight Full Color Outdoor Advertising Led Display Billboard P6.4-12.8mm

Product Details:

Place of Origin: China
Brand Name: Bakovision
Certification: CE ETL FCC CCC
Model Number: BDF Series

Payment & Shipping Terms:

Minimum Order Quantity: 1 sqm
Price: $399~999
Packaging Details: Wooden case or flight case
Delivery Time: 15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10,000 sqm/month
Detailed Product Description
LEDs: Nationstar Pannel Material: Steel/Die-Casting Aluminum
Servicing: Front/Rear Viewing Angle: 160°/140°
Refresh Rate: >1920Hz Contrast Ratio: 2000:1/4000:1
Brightness: >5500nits IP Rating(Front/Rear): IP65/IP54
High Light:

led digital billboard

,

outdoor led billboard

 Lightweight Die-Casting Aluminum Outdoor Billboard LED Display P6.4-12.8mm​


Specification

  BDF-6 BDF-8 BDF-10 BDF-12
Physical Pitch 6.4mm 8mm 10.66mm 12.8mm
Pixel Configuration SMD2727 SMD2727 SMD3535 SMD2727
Pixel Density 24,414pixels/m² 15,625pixels/m² 8,800 pixels/m² 6,103 pixels/m²
Module Dimensions 512×256mm 512×256mm 512×256mm 512×256mm
Panel Dimensions 1024×768×100mm 1024×768×100mm 1024×768×100mm 1024×768×100mm
NO. of Modules Per Panel 2×3 2×3 2×3 2×3
Physical Resolution of Module 80×40dots 64×32dots 48×24dots 40×20dots
Physical Resolution of Panel 160×120dots 128×96dots 96×72dots 80×60dots
Panel Material Die-Casting Aluminum Die-Casting Aluminum Die-Casting Aluminum Die-Casting Aluminum
Single Cabinet Weight 35kg 35kg 35kg 35kg
Grayscale 16bit 16bit 16bit 16bit
Colors 281trillion 281trillion 281trillion 281trillion
Contrast Ratio 2000:1/4000:1 2000:1/4000:1 2000:1/4000:1 2000:1/4000:1
Average Power Consumption 240W/ panel 350W/ /m² 350W/ /m² 350W/ /m²
Max Power Consumption 600W/ panel 700W/ /m² 700W/ /m² 700W/ /m²
Refresh Rate >1920Hz >1920Hz >1920Hz >1920Hz
Brightness >5500nits >5500nits >5500nits >5500nits
Expected Lifetime 100,000Hrs 100,000Hrs 100,000Hrs 100,000Hrs
Servicing Front/Rear Front/Rear Front/Rear Front/Rear
IP Rating(Front/Rear) IP65/IP54 IP65/IP54 IP65/IP54 IP65/IP54



































































Features



1.  High refresh rate and contrast rate. Suitable brightness adjustable for outdoor day and night.



Lightweight Full Color Outdoor Advertising Led Display Billboard P6.4-12.8mm 0



















2. Outdoor waterproof with IP65 to adapt to all kinds of weather conditions.



Lightweight Full Color Outdoor Advertising Led Display Billboard P6.4-12.8mm 1



















































3. Made with die-casting aluminum, lightweight and slim. In addition, made with die-casting aluminum better for heat dissipation and no fan design more quiet.Lightweight Full Color Outdoor Advertising Led Display Billboard P6.4-12.8mm 2



















































4. Fast installation and easy maintenance.



Lightweight Full Color Outdoor Advertising Led Display Billboard P6.4-12.8mm 3











































5. Cabinet can be transformed to be perimeter display adding with ground adjustable bracket and protection foam bumper.



Lightweight Full Color Outdoor Advertising Led Display Billboard P6.4-12.8mm 4









































About us



Shenzhen BAKO VISION Technology Co., Ltd, started in Shenzhen in 2005, a world class manufacturer of technologically advanced LED displays, focusing on high end professional customers among domestic and overseas markets. BAKOVISION is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.



Lightweight Full Color Outdoor Advertising Led Display Billboard P6.4-12.8mm 5













































































































































FAQ

1. Are you trading company or manufacturer?
We are a professional led screen manufacturer.



2. How to payment?

We accept the L/C, T/T, Western Union.



3. What is the packing method?

We usually use plywood case or flight case.



4. How about the delivery time?

We will ship within 30 working days after you placed the order, but the specific delivered time will be affected by the shipping company and shipping details.



5. Do you provide samples ? Is it free or extra?

We provide samples if you need, but the customers have to pay the sample cost and the courier cost.
