P10 Outdoor SMD3535 Waterproof LED Billboard Display
Product Details
| Pixel Configuration: | SMD3535 | Panel Material: | Aluminium |
|---|---|---|---|
| Single Cabinet Weight: | 70/50kg/sqm | Processing: | 16bit |
| Contrast Ratio: | 2000:1 | IP Rating（front/rear）: | IP65/IP54 |
| Highlight |
SMD3535 Waterproof LED Billboard Display,FCC Waterproof LED Billboard Display,15625pixels/M2 Outdoor LED Billboard |
||
Product Description
BSP Series
18-BSP.pdf
Outdoor LED Display for Stadium specifications:
| BSP-8 | BSP-10 | BSP-16 | |
| Physical Pitch | 8mm | 10mm | 16mm |
| Pixel Configuration | SMD3535 | SMD3535 | SMD3535 |
| Pixel Density | 15625pixels/m² | 10,000pixels/m² | 3,906 pixels/m² |
| Module Dimensions(W*H)(mm) | 256*256 | 320*320 | 256*128 |
| Panel Dimensions(mm) | 1280*768*187 | 1280*960*187 | 1280*896*187 |
| NO. Of Modules Per Panel(W*H) | 5*3 | 4*3 | 5*7 |
| Physical Resolution of Module(W*H) | 32*32 | 32*32 | 16*8 |
| Physical Resolution of Panel(W*H) | 160*96 | 128*96 | 160*56 |
| Panel Material | Aluminium | Aluminium | Aluminium |
| Single Cabinet Weight | 70/50kg/m² | 70/50kg/m² | 70/50kg/m² |
| Processing | 16bit | 16bit | 16bit |
| Colour Number | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 2000:1 | 2000:1 | 2000:1 |
| Average Power Consumption | 360W/panel | 360W/panel | 360W/panel |
| Max. Power Consumption | 900W/panel | 900W/panel | 900W/panel |
| Operating Temp/Humidity | -20ºC-50ºC/10%-90% | -20ºC-50ºC/10%-90% | -20ºC-50ºC/10%-90% |
| Storage Temp/Humidity | -20ºC-50ºC/10%-90% | -20ºC-50ºC/10%-90% | -20ºC-50ºC/10%-90% |
| Refresh Rate | >1920Hz | >1920Hz | >1920Hz |
| Brightness | >6500 nits | >6500 nits | >6500 nits |
| Horizontal Viewing Angle | 160° | 160° | 160° |
| Vertical Viewing Angle | 140° | 140° | 140° |
| Expected Lifetime | 100,000Hrs | 100,000Hrs | 100,000Hrs |
| IP Rating (Front/Rear) |
IP65/IP54 | IP65/IP54 | IP65/IP54 |
| Servicing | Front/Rear | Front/Rear | Front/Rear |
Ultimate, Outdoor, Sports Display
Fast to Install and Dismantle
High Refresh Rate for Live Camera
Outdoor Rated
IP65 rating for front and rear
Suitable brightness adjustable for outdoor day and night
5500-8000 nits brightness
Superior Electrical Features
Vivid and brilliant colors
16 Bit signal processing, 2500-4000Hz refresh rate
Built-in data and power redundancy for ultimate reliability
Fast Installation and Easy Maintenance
Fast lock system design guarantees a quick and easy installation
Fast access to modules, cables, power and data boxes
Versatile Dual Purpose Design
Removing the ground adjustable bracket and protection foam bumper can be transformed to be a square solid screen
Available for truss hanging, ground stacking, wall mounting
Applications:
Company Information:
LED Vision Technology Limited , started in Shenzhen in 2005, a world class manufacturer of technologically advanced LED displays, focusing on high end professional customers among domestic and overseas markets. BAKOVISION is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.
BAKO VISION contains of experienced team leaders and each of them has been working in LED display industry over 10 years. All of our R&D, Production, Sales, Technical Support depts….are running efficiently and smoothly by our great team work, moreover, delivering qualified product and offering timely pre-after service are also assured by BAKO VISION team.
BAKO VISION product lines have include UHD fine pitch, I/O rental, I/O fixed install, transparent screen, advertising poster, foldable screen, flexible screen, curtain, floor LED, perimeter display… meanwhile, based on our experienced R&D team and comprehensive management, we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.
BAKO VISION main markets are among America, Europe, Middle East and Asia, all of our products are certificated by RoHS,CCC,CE,FCC,ETL,UL. Standing firmly by quality, winning firmly by proficient, in the past years of development, BAKO VISION continuous growth and brand positioning are all relied onto the long term partnership with variety channel customers over 120+ countries.
