600-1000 Nits Indoor HD LED Display Full Color P1.25 IP40 For Meeting Room
Product Details
| Small Pixel Pitch Full Color P1.667 Indoor LED Display For Meeting Room: | P1.25mm | Module Size: | 150*168.75mm |
|---|---|---|---|
| Cabinet Size: | 600*337.5mm | No. Of Modules Per Panel (W*H): | 4*2 |
| Panel Material: | Die-casting | Weight: | 6kg/panel |
| Gray Scale: | 16 Bit | Colours: | 281 Trillion |
| Contrast Ratio: | 2,000:1 | Avg Power Consumption: | 300W/sqm |
| Max Power Consumption: | 600W/sqm | Brightness: | 600~1000nits |
| Refresh Rate: | 2880Hz | Vertical Viewing Angle: | 160° |
| Horizontal Viewing Angle: | 140° | Expect Lifetime: | 100,000Hrs |
| Servicing: | Front | IP Rating: | IP40 |
| Operating Temp/Humidity: | -20℃-50℃/10%-90% | Storage Temp/Humidity: | -40℃-60℃/10%-85% |
| Highlight |
hd led video wall,modular led display |
||
Product Description
600-1000 Nits Indoor HD LED Display Full Color P1.25 IP40 For Meeting Room
Indoor LED Display Specification:
HD LED Display High Definition Fine Pitch Full Color P1.25 Indoor LED Display for Meeting Room
Indoor LED Display Parameter:
| Model | UHD-1.2 | UHD-1.5 | UHD-1.8 | UHD-2.3 |
| Pixel Pitch | 1.25mm | 1.56mm | 1.87mm | 2.34mm |
| Cabinet Size | 600*337.5mm | 600*337.5mm | 600*337.5mm | 600*337.5mm |
| Cabinet Weight (kg) | 6 | 6 | 6 | 6 |
| Brightness(cd/m²) | 600~800 | 600~800 | 600~800 | 600~800 |
| Refresh Rate | ≥2880Hz | ≥2880Hz | ≥2880Hz | ≥2880Hz |
| Viewing Angle(H/V) | 160°/140° | 160°/140° | 160°/140° | 160°/140° |
| Power Consumption (Max) W/m² | 600 | 600 | 600 | 600 |
| Power Consumption (Avg) W/m² | 300 | 300 | 300 | 300 |
| IP Rating | IP 40/IP 21 | IP 40/IP 21 | IP 40/IP 21 | IP 40/IP 21 |
Advantage:
Our company also can arrange our engineers to provide you professional installation guide and training for free via remote control, video and phone.
All of products will be tested many times and 100% promise the products are well before shipping.
The products can be customized according to your projects and offer you the CAD drawing for free.
We guarantee all of our displays, modules, spare parts for full two years. During the time, we will replace or fix our goods for free if there is something wrong with them.
Service
1.24-hour hotline service, including counseling and technical guidance.
2. On-line service.
3. Failure maintenance of LED panels.
4. Free professional technical training
5. Paid software upgrade.
6. Warranty service.
7. Engineering technical service.
FAQ:
Q1. Can I have a sample order for LED Display?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: Sample needs 3-5 days, mass production time needs 10-15days for order quantity more than
Q3. Do you have any MOQ limit for LED light order?
A: Low MOQ, 1PC for sample checking is available
Q4. Is it OK to print my logo on LED light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q5: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
Company Information:
LED Vision Technology Limited , started in Shenzhen in 2005, a world class manufacturer of technologically advanced LED displays, is SHENZHEN BAKO LTD holding enterprises (Stock Code: 871745), focusing on high end professional customers among domestic and overseas markets. BAKOVISION is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.
BAKO VISION contains of experienced team leaders and each of them has been working in LED display industry over 10 years. All of our R&D, Production, Sales, Technical Support depts….are running efficiently and smoothly by our great team work, moreover, delivering qualified product and offering timely pre-after service are also assured by BAKO VISION team.
BAKO VISION product lines have include UHD fine pitch, I/O rental, I/O fixed install, transparent screen, advertising poster, foldable screen, flexible screen, curtain, floor LED, perimeter display… meanwhile, based on our experienced R&D team and comprehensive management, we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.
BAKO VISION main markets are among America, Europe, Middle East and Asia, all of our products are certificated by RoHS,CCC,CE,FCC,ETL,UL. Standing firmly by quality, winning firmly by proficient, in the past years of development, BAKO VISION continuous growth and brand positioning are all relied onto the long term partnership with variety channel customers over 120+ countries.
