Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21
Product Details
| Cabinet Material: | Die-casting Aluminum | Panel Dimention: | 500*500/500*1000 |
|---|---|---|---|
| Brightness: | >1,200nits | Contrast Ratio: | 4000:1 |
| Tube Chip Color: | Full Color | Pixel Configuration: | 1R1G1B |
| Highlight |
led publicity screens,indoor led billboard |
||
Product Description
Tools Free Installation Indoor Advertising Led Display Screen High Brightness
| BIR-III-2X | BIR-III-2 | BIR-III-3 | BIR-III-4 | |
| Physical Pitch | 2.6mm | 2.97mm | 3.91mm | 4.81mm |
| Pixel Configuration | SMD2121 | SMD2121 | SMD2121 | SMD2121 |
| Pixel Density | 147,456 pixels/㎡ | 112,896 pixels/㎡ | 65,536 pixels/㎡ | 43,264pixels/㎡ |
| Module Dimensions (W*H)(mm) | 250*250 | 250*250 | 250*250 | 250*250 |
| Panel Dimensions(mm) | 500*500*80/500*1000*80 | 500*500*80/500*1000*80 | 500*500*80/500*1000*80 | 500*500*80/500*1000*80 |
| Physical Resolution of Module(W*H) | 96*96 | 84*84 | 64*64 | 52*52 |
| Physical Resolution of Panel(W*H) | 192*192/192*384 | 168*168/168*336 | 128*128/128*256 | 104*104/104*208 |
| Panel Material | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum |
| Single Cabinet Weight | 8/14 kg/panel | 8/14kg/panel | 8/14kg/panel | 8/14kg/panel |
| Processing | 16 bit | 16 bit | 16 bit | 16 bit |
| Colours | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 4,000:1 | 4,000:1 | 4,000:1 | 4,000:1 |
| Average Power Consumption | 64/128W/panel | 64/128W/panel | 64/128W/panel | 64/128W/panel |
| Max Power Consumption | 192/384W/panel | 192/384W/panel | 192/384W/panel | 192/384W/panel |
| Refresh Rate | >1,920Hz | >1,920Hz | >1,920Hz | >1,920Hz |
| Brightness | >1,200nits | >1,200nits | >1,200nits | >1,200nits |
| Horizontal Viewing Angle | 160° | 160° | 160° | 160° |
| Vertical Viewing Angle | 140° | 140° | 140° | 140° |
| Max Staking | 20/10 | 20/10 | 20/10 | 20/10 |
| Max Hanging | 20/10 | 20/10 | 20/10 | 20/10 |
| Servicing | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
| IP Rating (Front/Rear) | IP40/IP21 | IP40/IP21 | IP40/IP21 | IP40/IP21 |
Product Features
User Friendly and Fast Installation
Truss hanging and ground support both available
Fast lock and handle designed user friendly
Front and rear access
Tools free installation
Unsupassed Color Uniformity
→Unique color calibration precess
→Tight bin selection for LED wavelength
→Deep black levels,contrat ratio 4000:1
Slim,Light Weight and Quiet
500mm*500mm or 500mm*1000mm
80mm thickness
1 person job
Fanless design
Smart Concave and Convex
Both 500mm*500mm and 500mm*1000mm cabinets are arc-ble
0°-10° concave and convex degree
How to measure brightness?
Nit is a unit to measure luminance over a square meter. It is also well-known as meter-lamberts.
NIT = meter-lamberts = candela per square meter (cd/m2)
Why does brightness matter?
At night, generally speaking, LED displays are always readable and working fine.
How to make a good choice between the flight case and wooden case?
Flight case is usually used for the rental LED display, which makes the transportation more convenient and protect the LED display better.
Wooden case is only for one time using transportation, such as the fixed installation LED display, wooden case is the best way for packing since the low cost and at the same time it can also ensure the safety of the LED display.
If your LED display screen system is for the rental use, please choose the flight case.
What is best viewing distance? How to calculate the best viewing distance of the LED display?
Best viewing distance refers to the distance between the LED Display and its viewers, where the people can see a whole and clear picture of the image on the LED display.
There’s 2 ways to calculate the best viewing distance: one is by the pixel pitch, one is by the diagonal.
