Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 4.81 | Cabinet Dimension: | 500*500/500*1000 |
|---|---|---|---|
| IP Rating: | IP65/IP54 | Brightness: | >6,000 |
| Servicing: | Front/Rear | Driving Method: | 1/16 Scan |
| Gray Scale: | 16bits | Control System: | Novastar |
| Highlight: | indoor full color led display,led publicity screens |
||
SMD LED Rental Display High Resolution 7kg Light Weight Panel 1200Nits Indoor
P4.81 Die-casting aluminum cabinet indoor rental led monitor display
Detachable Power & Control Backside
LED Cabinet’s backside power & receiving card control box can fast changed for easy maintenance.
Climb ladder Lock design
Each cabinet backside has handles can be climbed like a ladder. The handle can be used to lock the up and down cabinet.
Front & Rear Maintenance
It makes you easy to remove the modules without any tools and maintain the screen in front side as well as the rear side.
Indoor LED Display Parameters:
| Module | |
| Pixel Pitch | 4.81mm |
| Pixel Density | 43,264 pixel/sqm |
| Pixel Quantity (W * H) | 52* 52/52* 104mm |
| Module Size | 250 * 250/250 * 500mm |
| LED Type | SMD2525 |
| LED Configuration | 1R1G1B |
| Cabinet | |
| Resolution (W * H) | 104* 104/104* 208mm |
| Dimension(mm)(W * H) | 500*500/500*1000mm |
| Cabinet Material | Die-Casting |
| Cabinet Weight | 9/15kg/Panel |
| IP Rating(Front/Rear) | IP65/IP54 |
| Screen | |
| Brightness | >6,000nits |
| Input Voltage | AC 110/220±10% 50~60Hz |
| Gray Scale | 16bits |
| Refresh Rate | >1,920Hz |
| Dot Defects Rate | <0.0001 |
| Viewing Angle (H/V) | 160°/140° |
| Life Span | ≥100000hrs |
| Power Consumption(avg.) | 75/150W/Panel |
| Operating Temp/Humidity | ﹣20d℃～60℃ / 10%～60%RH |
| Storage Temp/Humidity |
﹣30℃～60℃ / 10%～60%RH |
