SMD2121 Indoor Rental LED Display Screen P2.97 500x500mm Die Casting Cabinet
Product Details
| Contrast Ratio: | 4000:1 | Processing: | 16bit |
|---|---|---|---|
| Pixel Configuration: | SMD2121 | Refresh Rate: | >1920Hz |
| Panel Size: | 500x500x80mm | Panel Material: | Die-casting Aluminum |
| Warranty: | 2Years | Physical Configuration: | 112896pixels/m² |
| Physical Pitch: | 2.97mm | Control System: | Novastar |
| Highlight |
indoor full color led display,indoor led billboard |
||
Product Description
P2.97 SMD Indoor HD LED Display Screen 500x500mm Die Casting Cabinet
BIR-I Indoor Rental LED Display
Advantages:
1) The appearance is very simple and elegant, looks very high-end
2) With specially designed fast lock system, easy to install and dismantle
3) The new structure design enables diversified installation to meet the hanging-up and stacking requirements.
4) High contrast rate up to 4000:1 by using black LED
5) High refresh rate with NOVA control system, no scanning line when photographed.
6) Due to the lightweight and low power consumption, it can reduce the labor cost, operating cost and transportation cost
7) 16bit color, showing very clear and vivid video and images.
8) Good thermal design, excellent heat dissipation even no fan installation
Superior Electrical Features
The dual signal backup port
UI LCD monitoring display indicates
Fast Installation and Easy Maintenance
Truss hanging and ground support both available
Cable-less between modules
Front and rear access
Tools free installation
Unsurpassed Color Uniformity
The unique color calibration process
Tight bin selection for LED wavelength
Deep black levels, contrast ratio 4000:1
Slim, Light Weight and Quiet
500mmx500mm or 500mmx1000mm cabinet
80mm thickness, 7 KG per cabinet
Fanless design
Specifications:
| Model | BIR-I-2 | BIR-I-3 | BIR-I-4 | BIR-I-6 |
| Physical Pitch | 2.97mm | 3.91mm | 4.81mm | 6.25mm |
| Pixel Configuration | SMD2121 | SMD2121 | SMD2121 | SMD3528 |
| Pixel Density | 112896 pixels/m² | 65536 pixels/m² | 43264 pixels/m² | 25600 pixels/m² |
| Module Dimensions (W× H) (mm) |
250*250/250*500 | 250*250/250*500 | 250*250/250*500 | 250*250/250*500 |
| Panel Dimensions (mm) | 500*500*80 500*1000*80 |
500*500*80 500*1000*80 |
500*500*80 500*1000*80 |
500*500*80 500*1000*80 |
| NO .of Modules Per Panel (W × H) | 2x2 | 2x2 | 2x2 | 2x2 |
| Physical Resolution of Module ( W× H) | 84*84/64*168 | 64*64/64*128 | 52*52/52*104 | 40*40/40*80 |
| Panel Material | 168*168/128*336 | 128*128/128*256 | 104*104/104*208 | 80*80/80*160 |
| Single Cabinet Weight | 7/13KG/Panel | 7/13KG/Panel | 7/13KG/Panel | 7/13KG/Panel |
| Panel Material | Die-Casting Aluminum | Die-Casting Aluminum | Die-Casting Aluminum | Die-Casting Aluminum |
| Processing | 16bit | 16bit | 16bit | 16bit |
| Colour Number | 281trillion | 281trillion | 281trillion | 281trillion |
| Contrast Ratio | 4000:1 | 4000:1 | 4000:1 | 4000:1 |
| Average Power Consumption | 60/120W/Panel | 60/120W/Panel | 60/120W/Panel | 60/120W/Panel |
| Max Power Consumption | 110/400W/Panel | 110/400W/Panel | 110/400W/Panel | 110/400W/Panel |
| Operating Temperature | -10~60ºC/10~60ºC | -10~60ºC/10~60ºC | -10~60ºC/10~60ºC | -10~60ºC/10~60ºC |
| Storage Temperature | -30~60ºC/10~60ºC | -30~60ºC/10~60ºC | -30~60ºC/10~60ºC | -30~60ºC/10~60ºC |
| Refresh Rate | >1920Hz | >1920Hz | >1920Hz | >1920Hz |
| Brightness | 900-1200nits | 900-1200nits | 900-1200nits | 900-1200nits |
| Horizontal Viewing Angle | 160° | 160° | 160° | 160° |
| Vertical Viewing angle | 140° | 140° | 140° | 140° |
| Max Stacking | 20/10 | 20/10 | 20/10 | 20/10 |
| Max Hanging | 20/10 | 20/10 | 20/10 | 20/10 |
| Expected Lifetime | 100,000hours | 100,000hours | 100,000hours | 100,000hours |
| Servicing | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
| IP Rating (Front/Rear) | IP40/IP21 | IP40/IP21 | IP40/IP21 | IP40/IP21 |
| Certification | CCC,CE,FCC,ETL | CCC,CE,FCC,ETL | CCC,CE,FCC,ETL | CCC,CE,FCC,ETL |
About us:
LED Vision Technology Limited , Stock Code: 871745, started in Shenzhen in 2005, a professional manufacturer of technologically advanced LED displays, is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.
BAKO VISION product lines have included I/O HD, Creative, Media LED screen, meanwhile, based on our experienced R&D team,
we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.
FAQ:
Q1. Are you trading company or manufacturer?
A: We are a professional led display manufacturer OVER FOURTEEN YEARS.
Q2. What's your payment term?
A: T/T, Western Union, L/C
Q3. Do you provide samples ? is it free or extra?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q4. How about your delivery time?
A: Generally, the sample needs 5-7 days, 15-25 days working days for batch order
Q5. How do you ship the goods and how long does it take to arrive?
A: We usually ship goods by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Air Freight and sea shipping are also optional.
Q6. Do you offer a guarantee for the products?
A: Yes, we offer 2 years warranty for our products. we have a warehouse in the USA and our engineer stay in the USA
to deal with after-sales and provide technical support.
Q7: How can I get technical support?
A: We will train in our factory and send video for showing. The training includes system use, system maintenance,
and equipment protection. We often attend exhibitions around the world every year, so we can visit you if you need at that time.
