Product Details:
Payment & Shipping Terms:
|
| Screen Dimension: | Customized | Tube Chip Color: | Full Color |
|---|---|---|---|
| Usage: | Indoor | Pixels: | 6mm |
| Display Function: | Video,text,message,image,picture | Brightness: | 1200cd/sqm |
| Warranty: | 2 Years | Module Size: | 192x192mm |
| Life Span: | 100000hours | Application: | Indoor Advertising,video Commercial Ad |
| Color: | 1R1G1B,Full-color | Pixel Density: | 111,111pixels/m2 |
| Refresh Rate: | ≥1920 Hz | Pixel Pitch: | 3mm |
| High Light: | Aluminum Panel Indoor Fixed LED Display,IP40 RGB Indoor Fixed LED Display,1200cd/Sqm Fixed LED Advertising Display |
||
Application:
Indoor fixed led display prevails in many Indoor places.
Widely used in advertising, sports, industrial enterprises, transportation, stations, terminals, airports, construction, education system and other public places.
Feature:
Seamless connection: Our special connector design makes it easy to install, reducing gaps between modules..
The latest shockproof technology brings you a more stable cabinet and longer life span.
The designed with aluminium die-casting technology making it possible to adapt all kinds of weather.
Customized design:According to customers' requirements, our product can be designed with different shapes.
Cabinet locking system can connect cabinets quickly and easily,making seamless installation available.
Advantages :
This product designed with die-casting aluminum, which makes it more stable and effective.
Lightweight makes it easy to operate and install.
The special splicing design realizes a variety of styles, so that the products meet the diverse requirements of customers.
Our products perform well in waterproof, antifreeze and high temperature resistance.
The product has been passed the dust-proof and water-proof, achieving protection standards IP43.
All module edges have made strong compression, which makes the cabinet have better flatness and is not easily deformed.
The box with a sliding iron top, bottom chute, and optional locking device to fine-tune the gap and ensure seamless between the boxes. Please do not squeeze the entire screen which ensure good surface smoothness
Parameter:
| Model | BIF3 |
| Pixel Pitch | 3mm |
| Unit Size | 960mmx960mm |
| LED Type | SMD 2121 |
| Pixel / Unit | 192*192 |
| Unit Weight | 38kg |
| Viewing Angle(H/V) | 160°/140° |
| Application | Storage-40~60° C, Working-20~50° C |
| Protection Level(Front/Rear) | IP40/IP21 |
| Power Consumption(AVG.) | 300w/m2 |
| Driving | 1/32 Scan(or 1/16 scan) |
| Frame Refresh | ≥ 60Hz |
| Refresh Rate | >1920Hz |
| Processing | 16bit |
| Max Brightness | >1200nits |
| Power Supply | AC110V/240V, 50~60Hz |
| MTBF | ≥ 1, 000 Hours |
| Life Span | ≥ 100000 Hours |
| Pixel Failure | < 0.0003 |
