Pixel Pitch 3.91mm Indoor Full Color LED Display Die Casting Aluminum
Product Details
| Pixel Pitch: | 3.91mm | Pixel Density: | 65,536pixels/m2 |
|---|---|---|---|
| Cabinet Dimension: | 500x500mm | Cabinet Material: | Die Casting Aluminum |
| Ingress Protection(front/rear): | IP40 | MTBF: | ≥1000hrs |
| Pixel Failure: | <0.0003 | ||
| Highlight |
3.91mm Indoor Full Color LED Display,RoHS Indoor Full Color LED Display,3.91mm Indoor LED Display Screen |
||
Product Description
Pixel Pitch 3.91mm Indoor Full Color LED Display Die Casting Aluminum
Light weight P3.91 indoor led video panel with Nationstar leds
P3.91 indoor led video panel Specs
| BIR-II-3 | |
| Physical Pitch(mm) | 3.91mm |
| Pixel Configuration | SMD2121 |
| Pixel Density | 65.536 pixels/sqm |
| Module Dimensions (W × H) (mm) | 250x250 |
| Panel Dimensions (mm) | 500x500x80/500x1000x80 |
| No. of Modules Per Panel (W × H) | 2x2/2x4 |
| Physical Resolution of Module (W x H) | 64x64 |
| Physical Resolution of Panel (W x H) | 128x128/128x256 |
| Panel Material | Die-casting Aluminum |
| Single Cabinet Weight | 8/14 kg / panel |
| Gray Scale | 16 bit |
| Colours | 281 trillion |
| Contrast Ratio | 4,000:1 |
| Average Power Consumption | 325 W / ㎡ |
| Max Power Consumption | 780 W / ㎡ |
| Operating Temp/Humidity | -10°-60℃/10%-60% |
| Storage Temp/Humidity | -30°-60℃/10%-60% |
| Refresh Rate | >1,920 Hz |
| Brightness | ≥1,200nits |
| Horizontal Viewing Angle | 160° |
| Vertical Viewing Angle | 140° |
| Expected Lifetime | 100,000 Hrs |
P3.91 indoor led video panel features:
1. Rental Die-Casting Aluminum structure
2. Lightweight
3. Seamless Splicing
4. Excellent thermal management
5. Quick lock system, easy installation
6. Wide viewing angle
7. Working status indicator
8. The pitch 8mm led rental display with High-performance aluminum alloy frame with the weight only
10kg, which can save transportation cost and reduce labor intensity effectively.
9. Using quick rim lock to connect left-right and up-down cabinets, needs only 10s to install one cabinet,
very quick and easy for installing
10. Nanotechnology applied in the module, the protection rate can reach IP65.
11. Using the design of removable dowel pin, so a single cabinet can be taken out from the whole screen to have a repairment.
P3.91 indoor led video panel details:
1. Front access module makes easy maintenance service;
2. Detachabel power box design;
3. Corner protecor protects leds in all corners;
