Product Details:
Payment & Shipping Terms:
|
| Cabinet Dimension: | 500x500mm | Certificates: | CE RoHS & UL |
|---|---|---|---|
| Life-span: | 50,000hours | Controll System: | Novastar Or Linsn |
| Led Chip: | Epistar, Cree, Nichia | Power Supply: | Meanwell |
| Cabinet Material: | Aluminum Die-casting | ||
| Highlight: | P4.81 Outdoor Rental LED Display,RoHS Outdoor Rental LED Display,RoHS P4.81 Outdoor LED Display |
||
Front Service P4.81 Outdoor Rental LED Display With 50x50cm Panel
Front service P4.81 outdoor display with 50x50cm panel in Frankfurt
P4.81 Outdoor Rental LED Display features:
1. Magnetic moduel but with IP65 rate;
2. Corner protector protects cornered Leds;
3. Handle for fastening led module;
P4.81 Outdoor Rental LED Display Specs
<
| BOR-M-4 | |
| Physical Pitch(mm) | 4.81 mm |
| Pixel Configuration | SMD 2525 / 2727 |
| Pixel Density | 43,264 pixels/m² |
| Module Dimensions (W × H) (mm) | 250x250 |
| Panel Dimensions (mm) | 500x500x80/500x1000x80 |
| No. of Modules Per Panel (W × H) | 2*2/2*4 |
| Physical Resolution of Module (W x H) | 52 × 52 |
| Physical Resolution of Panel (W x H) | 104 × 104 / 104 × 208 |
| Panel Material | Die-casting Aluminum |
| Single Cabinet Weight | 9 / 15 kg/panel |
| Gray Scale | 16 bit |
| Colours | 281 trillion |
| Contrast Ratio | 4,000:1 |
| Average Power Consumption | 320 W / ㎡ |
| Max Power Consumption | 780 W / ㎡ |
| Operating Temp/Humidity | -20°-60℃/10%-60% |
| Storage Temp/Humidity | -30°-60℃/10%-60% |
| Refresh Rate | >1,920 Hz |
| Brightness | ≥6,000nits |
| Horizontal Viewing Angle | 160° |
| Vertical Viewing Angle | 140° |
| Expected Lifetime | 100,000 Hrs |
| Max Stacking | 10-20pcs |
| Max Hanging | 10-20pcs |
| Servicing | Front / Rear |
| IP Rating(Front/Rear) | IP65/IP54 |
| Scan Method | 1/13 Scan |
