Product Details:
Payment & Shipping Terms:
|
| Cabinet Dimension: | 500x500mm | Certificates: | CE RoHS & UL |
|---|---|---|---|
| Life-span: | 50,000hours | Controll System: | Novastar Or Linsn |
| Led Chip: | Epistar, Cree, Nichia | Power Supply: | Meanwell |
| Cabinet Material: | Aluminum Die-casting | ||
| High Light: | P3.91mm Big Screen Rentals Outdoors,P3.91mm Billboard Led Display,ROHS P3.91 Outdoor LED Display |
||
P3.91mm Big Screen Rentals Outdoors Epistar Cree Nichia LED Chip
Front service P3.91 outdoor display with 50x50cm panel in Frankfurt
P3.91 Outdoor Rental LED Display features:
1. Magnetic moduel but with IP65 rate;
2. Corner protector protects cornered Leds;
3. Handle for fastening led module;
P3.91 Outdoor Rental LED Display Specs
| BOR-I-3 | |
| Physical Pitch | 3.91mm |
| Pixel Configuration | SMD1921 |
| Pixel Density | 65536 pixels/m² |
| Module Dimensions (W × H) (mm) | 250 × 250 / 250×500 |
| Panel Dimensions (mm) | 500 × 500 × 80 |
| 500 × 1000 × 80 | |
| NO .of Modules Per Panel (W × H) | 2 × 2 |
| Physical Resolution of Module (W × H) | 64×64/64×128 |
| Physical Resolution of Panel (W × H) | 128×128/128×256 |
| Panel Material | Die-Casting Aluminum |
| Single Cabinet Weight | 9/ 15 kg/panel |
| Gray Scale | 14-16 bit |
| Colors | 281 trillion |
| Contrast Ratio | 4,000: 1 |
| Average Power Consumption | 75 /150 W/m² |
| Max Power Consumption | 225 /550 W/m² |
| Operating Temp/Humidity | -20ºC - 60ºC / 10% - 60% |
| Storage Temp/Humidity | -30ºC - 60ºC / 10% - 60% |
| Refresh Rate | >1,920 Hz |
| Brightness | >5000 nits |
| Horizontal Viewing Angle | 160° |
| Vertical Viewing angle | 140° |
| Expected Lifetime | 100, 000 Hrs |
| Max Stacking | 10-20pcs |
| Max Hanging | 10-20pcs |
| Servicing | Front / Rear |
| IP Rating (Front/Rear) | IP 65/ IP 54 |
| Scan Method | 1/16 Scan |
