Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 3.91mm | Pixel Density: | 65,536pixels/m2 |
|---|---|---|---|
| Cabinet Dimension: | 500x500mm | Cabinet Material: | Die Casting Aluminum |
| Ingress Protection(front/rear): | IP65/IP54 | MTBF: | ≥1000hrs |
| Pixel Failure: | <0.0003 | ||
| Highlight: | P3.91 Stage Rental LED Display,IP65 Stage Rental LED Display,P3.91 LED Display Video Wall |
||
Waterproof IP65 P3.91 Outdoor led video wall with 50x100cm panel
P3.91 Outdoor Rental Led display Features
1, Front access module makes easy maintenance service;
2, Super thin and light with aluminum cabinet design.
3, Good anti-UV and anti-oxidation performance.
4, Large viewing distance, 140° in horizontal, 140° in vertical.
5, Excellent flatness and no splicing gap between modules
6, Quick installation and removal with facile connection lock
7. After-sales service conducted in USA, parts no need to send back to China;
Panels of P3.91 outdoor led video wall
Specs of P3.91 outdoor led video wall
| BOR-I-3 | |
| Physical Pitch | 3.91mm |
| Pixel Configuration | SMD 1921 |
| Pixel Density | 65536 pixels/m² |
| Module Dimensions (W × H) (mm) | 250 × 250 / 250×500 |
| Panel Dimensions (mm) | 500 × 500 × 80 |
| 500 × 1000 × 80 | |
| NO .of Modules Per Panel (W × H) | 2 × 2 |
| Physical Resolution of Module (W × H) | 64×64/64×128 |
| Physical Resolution of Panel (W × H) | 128×128/128×256 |
| Panel Material | Die-Casting Aluminum |
| Single Cabinet Weight | 9/ 15 kg/panel |
| Gray Scale | 14-16 bit |
| Colors | 281 trillion |
| Contrast Ratio | 4,000: 1 |
| Average Power Consumption | 75 /150 W/m² |
| Max Power Consumption | 225 /550 W/m² |
| Operating Temp/Humidity | -20ºC - 60ºC / 10% - 60% |
| Storage Temp/Humidity | -30ºC - 60ºC / 10% - 60% |
| Refresh Rate | >1,920 Hz |
| Brightness | >5000 nits |
| Horizontal Viewing Angle | 160° |
| Vertical Viewing angle | 140° |
| Expected Lifetime | 100, 000 Hrs |
