Outdoor LED Billlboard P10 Highway Fixed Advertising LED Screen
Product Details
| Pixel Pitch: | P3, P4, P5, P6.67, P8, P10, P16 | Cabinet Size: | Customized |
|---|---|---|---|
| Pannel Material: | Steel/Magnesium Alloy/Aluminum | Servicing: | Front/Rear |
| IP Rating(Front/Rear): | IP65/IP54 | Brightness: | ＞5500nits |
| Refresh Rate: | ＞1920Hz | Contrast Ratio: | 2000:1 |
| Highlight |
5500nits Outdoor LED Billlboard,10mm Pixel Outdoor LED Billlboard,360W/M2 Fixed Advertising LED Screen |
||
Product Description
Outdoor Large Billlboard P10 Highway Fixed Advertising LED Screen Commercial LED Panel
BOF Series (BOF-B.pdf)
Outdoor LED Billboard
| Specifications | |
|---|---|
| Pixel Pitch(mm): | 3 / 4 / 5 / 6.67 / 8 / 10 / 16 |
| Brightness(nits): | Up to 7000 |
| Refresh Rate(Hz): | >1920 |
| Key Point: | Most common outdoor LED billboard |
Key Features
- Customized Cabinet Size and Design.
- Steel/ Aluminum/Magnesium alloy Cabinet.
- Back Service.
- SMD 3in1 Technology.
- Waterproof with IP65.
- Wide View Angle.
Outdoor Fixed Screen Parameters
| BOF-4 | BOF-5 | BOF-6 | BOF-8 | BOF-10 | |
| Physical Pitch | 4mm | 5mm | 6.67mm | 8mm | 10mm |
| Pixel Configuration | SMD1921 | SMD2727 | SMD2727 | SMD3535 | SMD3535 |
| Module Dimensions | 320×160mm | ||||
| Panel Dimensions(W × H) | Customized | ||||
| Physical Resolution of Module (WxH) | 80x40 | 64x32 | 48×24 | 40x20 | 32×16 |
| Panel Material | Steel/Aluminum/Magnesium alloy | ||||
| Grayscale | 16bit | ||||
| Colors | 281trillion | ||||
| Average Power Consumption | 360W/m2 | ||||
| Max. Power Consumption | 900 W/m2 | ||||
| Refresh Rate | ＞1920Hz | ||||
| Brightness | > 5000 nits | > 5500 nits | > 6000 nits | > 6200 nits | > 6500 nits |
| Expected Lifetime | 100,000 Hrs | ||||
| Maintenance Way | Rear | ||||
| IP Rating(Front/Rear) | IP65/IP54 | ||||
6 Main points to choose the right Outdoor LED Signage
1. Cabinet - the most important parts, it must be designed as strictly waterproof, leakproof, drainage measures design.
2. Lightning protection device - this device should be installed on the building with the outdoor billboard led display, ensure the cabinets are grounded well, and the grounding resistance is less than 3 ohms. So, the power source can be discharged in time by large current.
3. Cooling system equipment - If the temperature and weather in your country is always very hot or could, then the air conditional cooling equipment must be installed for the outdoor billboard led display, you need to ensure the internal temperature is between -10 degrees ~ 40 degrees.
4. Brightness - The brightness of the outdoor billboard LED display is always very important to suit with your local environment, you need to make sure the height of installation place, view distance from the people, natural sun brightness, installation environment when you are discussing the solutions with your supplier.
5. Maintenance way - Front access/Rear access, it's according to that do you have the space to repair the outdoor billboard from the rear or front the installation.
6. Control system - Synchronous/Asynchronous.
About Bako Vision
- Over 10 Years Experience on LED Display Screen Manufacturing in China.
- 3 Years High Quality Warranty Provided.
- Global Quality Standard with CE, EMC, ROHS, ETL, UL, FCC, ISO9001 Certificated.
- Overseas Customer in 120+ Countries in The World.
- Full Capable to Provide the Tailor Work of OEM, ODM.
FAQ:
Q1. What is pixel pitch?
A1: The center distance between two adjacent pixels, the smaller the spacing, the shorter the visible distance. The industry is often referred to as P to indicate the point spacing.
Q2. What is pixel density?
A2: Also known as dot matrix density, it usually refers to the number of pixels per square meter of display.
Q3. What is LED Cabinet?
A3: A small unit consisting of several display pixels that are structurally independent and can form an LED display. Typical are 8*8, 8*7, etc.
Q4. What is LED module?
A4: It has a basic unit with circuit and installation structure, display function, and display function by simple assembly.
Q5. What is LED display?
A5: A display screen composed of an array of LED devices by a certain control method.
Q6: What is the refresh rate ?
A6: The number of times the display screen is repeatedly displayed by the display in unit time.
