SMD2121 P2.97 Front Service Led Display 50x100cm Panel

SMD2121 P2.97 Front Service Led Display 50x100cm Panel
SMD2121 P2.97 Front Service Led Display 50x100cm Panel

Large Image :  SMD2121 P2.97 Front Service Led Display 50x100cm Panel

Product Details:

Place of Origin: Shenzhen,China
Brand Name: BAKO VISION
Certification: CE,ETL,RoHS,FCC,3C,UL
Model Number: P2.97

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Flight Case/Road Case
Delivery Time: 20-25 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000m²/month
Detailed Product Description
Pixel Pitch: 2.97mm Pixel Density: 112896pixels/m2
Cabinet Dimension: 500x1000mm Cabinet Material: Die Casting Aluminum
Ingress Protection(front/rear): IP40 MTBF: ≥1000hrs
Pixel Failure: <0.0003
High Light:

P2.97 Front Service Led Display

,

SMD2121 Front Service Led Display

,

112896pixels/M2 Stage Background Led Display

Front service P2.97 Indoor Rental Led display 50x100cm panel for new product launch



P2.97 Indoor Rental Led display Features

1, High brightness uniformity and color uniformity(≥95%).

2, Super thin and light with aluminum cabinet design.

3, Good anti-UV and anti-oxidation performance.

4, Large viewing distance, 140° in horizontal, 140° in vertical.

5, Excellent flatness and no splicing gap between modules

6, Quick installation and removal with facile connection lock



P2.97 Indoor Rental Led display Specs

  BIR-II-2
Physical Pitch(mm) 2.97
Pixel Configuration SMD2121
Pixel Density 112,896 pixels/sqm
Module Dimensions (W × H) (mm) 250x250
Panel Dimensions (mm) 500x500x80/500x1000x80
No. of Modules Per Panel (W × H) 2x2/2x4
Physical Resolution of Module (W x H) 52x52
Physical Resolution of Panel (W x H) 104x104/104x208
Panel Material Die-casting Aluminum
Single Cabinet Weight 8/14 kg / panel
Gray Scale 16 bit
Colours 281 trillion
Contrast Ratio 4,000:1
Average Power Consumption 310 W / ㎡
Max Power Consumption 750 W / ㎡
Operating Temp/Humidity -10°-60℃/10%-60%
Storage Temp/Humidity -30°-60℃/10%-60%
Refresh Rate >1,920 Hz
Brightness ≥1,200nits
Horizontal Viewing Angle 160°
Vertical Viewing Angle 140°
Expected Lifetime 100,000 Hrs



SMD2121 P2.97 Front Service Led Display 50x100cm Panel 0



SMD2121 P2.97 Front Service Led Display 50x100cm Panel 1

SMD2121 P2.97 Front Service Led Display 50x100cm Panel 2

SMD2121 P2.97 Front Service Led Display 50x100cm Panel 3

SMD2121 P2.97 Front Service Led Display 50x100cm Panel 4
