Back Front Service P4.81 Street Led Screen High Refresh Rate

Brand Name: BAKO VISION
Model Number: ODF-4
Place of Origin: China
Certification: CE,FCC,ROHS
Minimum Order Quantity: Negotiation
Price: Negotiation
Supply Ability: 7000m²/Month

Product Details


Pixel Pitch: 4.81mm LED Type: SMD1921
Gray Scale: 16bit Viewing Angle(H/V: 140°/140°
Data Refresh Rate: >1500Hz Pixel Failure: <0.0003
Highlight

P4.81 Street Led Screen

,

SMD1921 Street Led Screen

,

43264pixels/m2 Outdoor Advertising Led Display

Product Description

P4.81 Back and Front Service Outdoor Fixed LED Display High Refresh Rate LED Street Panel

8-BOF-F.pdf

An LED display is a flat panel display,which uses an array of light-emitting diodes as pixels for a video display. Their brightness allows them to use in outdoors where they are visible under the sunlight fir store signs and billboards.

Available range

commercial advertising, stadium, large-scale entertainment plazas, commercial centers, government public announcement, commercial streets, and railway stations etc

Product Features

1. Optional of convex shaped,concave shaped and wave shaped screens.

2. High gray scale and high refresh rate at even low brightness.

3. Black LED's offer high contrast ratios and sharp images quality.

4. Wide viewing angle up to140°. (Horizontal and Vertical)

5. 16bit (highest possible) color processing technology.

6. Standard cabinet with seamless joint.

7. The cabinet can be operate in all-weather for its slim design and waterproofing that with a protection level of class IP65 in front and IP54 in back.

8. Both front and back service,easy to installation and maintenance.

Model ODF-4
Pixel Pitch 4.81mm
Pixel Density 43264pixels/m2
LED Type SMD1921
LED Configuration 1R1G1B
Cabinet Dimension 1000mm*1000mm
Cabinet Resolution 208*208pixels
Cabinet Weight 65kg
Cabinet Material cold steel
Ingress Protection
(front/rear)
IP65/IP54
Brightness >5500nits
Viewing Angle(H/V) 140°/140°
Driving Method 1/9 scan
Frame Refresh ≥ 60Hz
Data Refresh Rate >1500Hz
Gray Scale 16bit
Power Consumption(avg.) 250w/m2
Input Voltage AC 110/220±10%
50~60Hz
Temperature
(operating/storage)
-20~50°C / -40~60°C
Humidity(operating/storage) 10%~90%RH
/ 10%~85%RH
MTBF ≥1000hrs
Life Span ≥50000hrs



Back Front Service P4.81 Street Led Screen High Refresh Rate 0





Why Choose Us?
1. 10 years experience of led display, CE, RoHS, FCC, C-Tick and ISO9001:2008 approved.

2. Quality test report for every order.
3. Free technician training.
4. Strict quality control from the raw material test to manufacturing, assembly and aging test;
5. Fast response and professional service, suggestions and solutions, special design and free lifelong consultation for you.

6. Special service for big project, such as stadium, exhibitions, squares and so on.
7.All products 24 months warranty and provides lifelong maintenance with free labor and service only charging raw materials with reasonable price.



Company Information:

LED Vision Technology Limited  , started in Shenzhen in 2005, a world class manufacturer of technologically advanced LED displays, focusing on high end professional customers among domestic and overseas markets. BAKOVISION is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.

BAKO VISION contains of experienced team leaders and each of them has been working in LED display industry over 10 years. All of our R&D, Production, Sales, Technical Support depts….are running efficiently and smoothly by our great team work, moreover, delivering qualified product and offering timely pre-after service are also assured by BAKO VISION team.

BAKO VISION product lines have include UHD fine pitch, I/O rental, I/O fixed install, transparent screen, advertising poster, foldable screen, flexible screen, curtain, floor LED, perimeter display… meanwhile, based on our experienced R&D team and comprehensive management, we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.

BAKO VISION main markets are among America, Europe, Middle East and Asia, all of our products are certificated by RoHS,CCC,CE,FCC,ETL,UL. Standing firmly by quality, winning firmly by proficient, in the past years of development, BAKO VISION continuous growth and brand positioning are all relied onto the long term partnership with variety channel customers over 120+ countries.
