6000CD/M² SMD1921 7mm Pixel Transparent LED Billboard

Glass Transparent LED Screens Billboard High Brightness Excellent Heat Sinking Rental LED Screen

Brief introduction:

Bako Vision Transparent LED display series is one kind of indoor transparent LED screens with a high transparency(up to 80%), lightweight and ultra thin,quick lock with no tools features.

The modular technology design makes it high efficient installation to build a large screen which is widely used in the stage, lice stations, showcases, car 4s shops, conference, exhibition center, chain store, shopping mall, squares and other large-scale indoor and outdoor and commercial events,etc.

Transparent LED billboard displays Advantages:

1. Super light weight easy install and dismount.

2. Easy maintenance, fast lock design make sure fast installation and dismount

3. Ultra thin design makes the screens is perfectly fusion with building

4. High transparency up to 80.Perfect lighting, visual like dreaming

5. More than 50% of energy than traditional displays, high efficiency and energy saving is the best choice

6. The standard module size is simple and elegant

7. The PCB board is the most narrow(3mm)

8. High transparency rate for front and back, have PC protection

9. Customized is available. Modern transparent LED displays have all kinds of types, the structures are complex,

the sizes are not the same, the standard cabinet can not meet all the needs of different projects.

Bako Vision can do customized the best product solution according to the reality situation, to ensure the permeability of transparent LED display, completeness of display and consistency.

10. Indoor installation for outdoor viewing.This makes easy installation and maintenance,safety, less approval processed than outdoor advertising

11. For Install methods, we can provide stand installation and hanging installation,all can be choice to meet your demands

Specification:

Model	BG
Pixel Pitch(H/V)	BG P3.9-7.8mm
Unit Size	1000mmx500mm
LED Type	SMD1921
Pixel / Unit	128*16
Unit Weight	14kg/sqm
Transparency	75%
Viewing Angle(H/V)	140° / 140°
Application	Storage-40~60°C, Working-20~50°C
Protection Level	IP30
Power Consumption(AVG.)	160w/m2
Frame Refresh	≥ 60Hz
Data Refresh Rate	>1500Hz
Processing	16bit
Brightness	>6500nits
Driving Method	1/4 scan
Power Supply	AC110V/240V, 50~60Hz
MTBF	≥1000 Hours
Life Span	≥100000 Hours
Pixel Failure	<0.0003

After-sale Service:

BAKO VISION offer two years warrenty for the products.
Once the two years warrenty period expired, BAKO VISION will charge the raw material cost for maintance.

BAKO VISIONwill not offer free maintance for the following circumstances:

1. Malfunction caused by misuse, including improper disassemble ,or testing and other misoperations.
2.Damage due to the user's misuse.
3. Shell damage or components damage in use.
Cost for After-sales technical support
BAKO VISION will arrange engineers to help with installation and maintance guidance, the clients should bear all the cost incurred for after-sales technical service, including visa fee, boarding fee ,foods ,transportations fee and so on.

Detailed Images:

LED Vision Technology Limited  , started in Shenzhen in 2005,a world class manufacturer of

technologically advanced LED displays,it is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.

BAKO VISION product lines have include I/O rantal,I/O fixed, UHD fine pitch, transparent screen,advertising poster,foldable screen… meanwhile, based on our experienced R&D team,and comprehensive management , we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.

FAQ

Q1:How to choose a proper led screen for your need?

A:You just need to think of 3 simple questions when you choose a led screen by yourself.
1.Will you use it indoor or outdoor?
2.Is it for rental use(need to be moved from one place to another place very often) or for fixed installation(to be installed in one place forever)?
3.what is the appoximate size of the led screen you would like to purchase?

Q2:Which pixel pitch should i choose?

A:There are many different pixel pitch from 1.667--20,25,30mm, there is a roughly principle-usually small pixel(1.667mm-10mm) used for indoor led screen, bigger pixel (10mm-30mm) used for outdoor led screen(for example high way huge advertisement).

Q3:Which control system should i choose?

A:There is both synchronous and asynchronous control system for led screen on the market,for big size led screen(usually more than 20sqm) need to use synchronous control system,below 20sqm it's up to you to use syn or asyn.But asyn control system's refresh rate is much lower than sync control system and for asyn control system, you can choose to use wifi,3G,4G etc wireless control.
