Product Details:
Payment & Shipping Terms:
|
| Physical Pitch: | 3.91mm | Panel Material: | Die-casting Aluminium |
|---|---|---|---|
| Module Size:: | 250mm*250mm | LED Chip: | Nationstar |
| Power Supply: | G-energy | Life Span: | 100,000 Hrs |
| High Light: | events led display,led rental display |
||
HD LED Video Wall Stage Rental LED Display Screen 500*500mm Panel 1920HZ
Products Description:
Cabinet size:500mm x 500mm
P3.91 Outdoor Rental LED display, P3.91mm pixel rental LED display LED screen LED video wall, Standard Size 500mmx1000mm or 500x500mm, P3.91mm led display screen high quality SMD LED Display Screen for rental use. P3.91 Rental LED display mainly used for performance, meetings, exhibitions, weddings, foundations, started opening, promotion and other activities,the stage background structures, lighting and sound equipment and special effects equipment rental places.
Products Features:
1.Die casting aluminum alloy natural heat dissipation, no fan mute design;
2.IP65 high waterproof and dust-proof, adapt to extreme weather;
3.High precision die casting aluminum box, thin and lightweight, greatly saving the cost of steel structure and transportation, installation costs;
4.Can choose to install, lift, creative assembly and other forms, to meet the needs of shopping malls, windows, leasing and other applications;
5. Support +/-7.5°curved large screen assembly
6.Supports two sizes of mixed and misaligned stitching
7.Quick assembling & disassembling: due to unique quick lock design, 2 seconds for assembling one panel
Parameter
| BOR-III-3 | |
| Physical Pitch | 3.91mm |
| Pixel Configuration | SMD1921 |
| Pixel Density | 65,536 pixels/m² |
| Module Dimensions(W*H)(mm) | 250*250/250*500 |
| Panel Dimensions(mm) | 500*500*80/500*1000*80 |
| NO. of Modules Per Panel (W*H) | 2*2 |
| Panel Material | Die-Casting Aluminum |
| Colors | 281Trillion |
| Processing | 16 Bit |
| Physical Resolution of Module(W*H)(mm) | 64*84/64*168 |
| Physical Resolution of Panel(W*H)(mm) | 128*128/128*256 |
| Single Cabinet Weight | 9/15kg/ panel |
| Average Power Consumption | 75/150W/panel |
| Max Power Consumption | 225/550W/panel |
| Brightness | >60,00nits |
| Viewing Angle | H:160°/ V:140° |
| Expected Lifetime | 100,000 Hrs |
| Servicing | Front/Rear |
| IP Rating(Front/Rear) | IP 65/IP54 |
| Max Stacking | 20/10 |
| Max Hanging | 20/10 |
| Refresh Rate | >1,920 Hz |
| Contrast Ratio | 4000:1 |
Outdoor Rated
Feature
● TUV Certificated and Reddot Awarded
● Front and Rear Access
● UI LCD monitoring display indicates the status
● Double data backup: if one data cable doesn’t work, perimeter led display still can work well
Outdoor Waterproof with IP65
Deep black levels, contrast ratio 4000:1
Suitable brightness adjustable for outdoor day and night
Slim, Light Weight and Quiet
● 500mmx500mm or 500mmx1000mm options
● 80mm thickness
● Fanless design
●Die casting aluminum material have a excellent heat dissipation performance to protect the module circuit
