Curved Digital SMD2727 Outdoor Full Color LED Video Wall P8 For Advertising Boards

Curved Digital SMD2727 Outdoor Full Color LED Video Wall P8 For Advertising Boards
Curved Digital SMD2727 Outdoor Full Color LED Video Wall P8 For Advertising Boards Curved Digital SMD2727 Outdoor Full Color LED Video Wall P8 For Advertising Boards Curved Digital SMD2727 Outdoor Full Color LED Video Wall P8 For Advertising Boards Curved Digital SMD2727 Outdoor Full Color LED Video Wall P8 For Advertising Boards

Large Image :  Curved Digital SMD2727 Outdoor Full Color LED Video Wall P8 For Advertising Boards

Product Details:

Place of Origin: CHINA
Brand Name: BAKO VISION
Certification: CCC, CE, FCC, ETL
Model Number: BDF

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Plywood Case/ Flight Case
Delivery Time: 20 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100,00 sqm / month
Detailed Product Description
Pixel Configuration: SMD 2727 Optional Models: Outdoor P5,P6.67,P8,P10
Panel Material: Aluminum Panel Dimensions (mm): 1024*768
Gray Scale (mm): 16bit Tickness: 100mm
Refresh Rate: >1920 Hz Single Cabinet Weight: 35 Kg
High Light:

roadside led display

,

outdoor waterproof led advertising panels

P8 Curved Digital SMD2727 Outdoor Full Color LED Video Wall for Advertising Boards



Product Features



1. Standard design, specific series, Lightweight Large Format, It is special formulated with module plastic material with deep black; it is strong and durable and its contrast is higher than conventional products, strong and durable.

2. Clear vivid image quality: Even in direct, full-on sunlight to ensure you attracts more audience to get short ROI of your LED screen's investment.

3. Easy maintenance also can ease the pressure on labor cost. Our product supports front service. Just seconds to remove the module and put on the new one is OK. Every place of our product is electronic isolated, which can ensure the security of the workers.

4. SMd 2727 led lamp


1) Superoir quality smd3535 led lamp by Nation star
2) Multiple waterproof,high reliabilty
3) White frame,improve brightness



Curved Digital SMD2727 Outdoor Full Color LED Video Wall P8 For Advertising Boards 0


Specifications



  BDF-5 BDF-6 BDF-8 BDF-10
Physical Pitch 5.33mm 6.4mm 8mm 10mm
Pixel Configuration SMD 1921 SMD 2727 SMD2727 SMD3535
Pixel Density 35,200 pixels/m² 24,414 pixels/m² 15,625 pixels/m² 8800 pixels/m²
Module Dimensions(W*H)(mm) 512*256
Panel Dimensions(mm) 1024*768*100
NO. of Modules Per Panel (W*H) 2*3
Panel Material Aluminum
Colors 281 trillion
Weight (kg/m²) 35kg
Processing 16 bit
Refresh Rate >1920 Hz
IP Rating IP65/ 54
Viewing Angle V:160 degree
H: 140 degree
Expected Lifetime 100,000 Hrs
Operating Temp/Humidity -20ºC-50ºC/
10%-90%
Storage Temp/Humidity -20ºC-50ºC/
10%-90%
Physical Resolution of Module(W*H)(mm) 96*48 48*48 32*32 32*32
Physical Resolution of panel(W*H)(mm) 192*144 192*144 160*96 128*96
Avg./ Max. Power Consumption 360/900W/ panel
Servicing Front/Rear


About Product



Curved Digital SMD2727 Outdoor Full Color LED Video Wall P8 For Advertising Boards 1



Die Casting, One Chassis,Variable Pitch Options

1. Lightweight Large Format, Slim and Smart

2. Ideal substitution for Traditional Cabinet

3. I/O advertising billboardas



Curved Digital SMD2727 Outdoor Full Color LED Video Wall P8 For Advertising Boards 2

Good heat dissipation

No matter for cabinet or for module frames, they are both die-casting aluminum, making sure of good heat dissipation. So screen can still work well in high temperature.



Curved Digital SMD2727 Outdoor Full Color LED Video Wall P8 For Advertising Boards 3



Smart and Variable

1. One standard chassis 1024mmx768mm, covering pitches from 2.6mm to 10.6mm

2. Suitable brightness adjustable for outdoor day and night

3. Deep black levels, contrast ratio 4000:1


Widely application

Wide application field: Advertising LED display, Stadium perimeter LED display, Mobile LED display for mobile media, shopping mall LED display for logo showing, bank & stock exchange LED display for rates showing, train & bus station, airport, telecommunication LED screen system for information showing and instruction, Stage performances and so on.



Curved Digital SMD2727 Outdoor Full Color LED Video Wall P8 For Advertising Boards 4



About us

Shenzhen BAKO VISION Technology Co., Ltd, started in Shenzhen in 2005, a world class manufacturer of technologically advanced LED displays, focusing on high end professional customers among domestic and overseas markets.BAKOVISION is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.



Curved Digital SMD2727 Outdoor Full Color LED Video Wall P8 For Advertising Boards 5




FAQ


1. How to install it after I received it?

We will offer you the drawing to guide you for installation, we could also offer drawing, software set up drawing or photo or arrange our engineer to help if needed.



2. How could I buy the products I need if there is no price in the website and could I get some samples first?

A: You can send your inquiry to us about the products you need,our sales will reply you within 24 hours to help you make the order.We welcome sample order to test and check quantity.



3. What is a custom LED display?

Custom LED displays can be designed to meet the needs of the user, taking into account all of the above for easy maintenance. Of course, maintenance can help to increase the service life of any electronic device, and measures are taken during the production process, so that maintenance costs are greatly reduced.

A custom LED display, as the name suggests, can control anything with any message you can think of. They are used in almost all industries, such as factories, banks, airports, universities, libraries, etc.

Custom LED displays are mounted on the wall or suspended from any ceiling for broadcasting information viewed from any distance. In addition, the brightness of these custom LED displays can be displayed very clearly at any distance.
