Full Color Outdoor Fixed LED Display P4 P6.67 P8 P10 For Railway Station Shopping Mall

Full Color Outdoor Fixed LED Display P4 P6.67 P8 P10 For Railway Station Shopping Mall
Full Color Outdoor Fixed LED Display P4 P6.67 P8 P10 For Railway Station Shopping Mall

Large Image :  Full Color Outdoor Fixed LED Display P4 P6.67 P8 P10 For Railway Station Shopping Mall

Product Details:

Place of Origin: China
Brand Name: BAKO VISION
Certification: CE,FCC,ROHS
Model Number: BOF-4

Payment & Shipping Terms:

Minimum Order Quantity: 1 square meter
Packaging Details: Flight case/Wooden Case
Delivery Time: 20-25days
Payment Terms: L/C, T/T, D/P, D/A, Western Union,O/A
Supply Ability: 7000m²/Month
Detailed Product Description
Pixel Pitch: 4mm LED Type: SMD1921
Gray Scale: 16bit Viewing Angle(H/V: 140°/140°
Data Refresh Rate: >1500Hz Pixel Failure: <0.0003
High Light:

roadside led display

,

street led screen

Full color Outdoor Fixed LED Display for railway station shopping mall P4 P6.67 P8 P10

9-BOF-B.pdf



Outdoor Fixed LED Display Feature:
1.Light weight: it can be loaded by one person, quick assembling, quick maintain, reduce. carrying, save costs.

2.Quick dismounting: adopt fast locking structure connected, firm, quick, beautiful.

3.Low release heat: low noise, low consumption, low cost, excellent thermal design and excellent thermal dispersion.

4.Concave and convex setup support: client can asselbly any shape of the led wall display to make different show effect compare with common led display panel.

5.IP65 rating from front and rear.

6.Wide viewing angle.

7. High refresh rate, high gray scale.

Full Color Outdoor Fixed LED Display P4 P6.67 P8 P10 For Railway Station Shopping Mall 0



Available range

commercial advertising, stadium, large-scale entertainment plazas, commercial centers, government public announcement, commercial streets, and railway stations etc

Full Color Outdoor Fixed LED Display P4 P6.67 P8 P10 For Railway Station Shopping Mall 1

Specifications:

  BOF-4 BOF-6
Physical Pitch 4 mm 6.67 mm
Pixel Configuration SMD 1818 SMD 2727
Pixel Density 62500 pixels/m² 22,376 pixels/m²
Module Dimensions(W*H)(mm) 320*160 320*160
Panel Dimentions(W*H)(mm) 960*960*150 960*960*150
NO. of Modules Per Panel (W*H) 3*6 3*6
Physical Resolution of Module (W*H) 80*40 48*24
Physical Resolution of Panel (W*H) 240*240 144*144
Panel Material Steel /Aluminum Steel /Aluminum
Weight (kg/m²) 65/45 65/45
Contrast Ratio 2,000:1 2,000:1
Average Power Consumption 360 W/panel 360 W/panel
Max Power Consumption 900 W/panel 900 W/panel
Brightness >6,500 nits >6,500 nits
Refresh Rate >1,920 Hz >1,920 Hz
Vertical Viewing Angle 160° 160°
Horizontal Viewing Angle 140° 140°
Servicing Front/Rear Front/Rear
Operating Temp/Humidity -20℃-50℃/10%-90% -20℃-50℃/10%-90%
Storage Temp/Humidity -20℃-50℃/10%-90% -20℃-50℃/10%-90%



Full Color Outdoor Fixed LED Display P4 P6.67 P8 P10 For Railway Station Shopping Mall 2

Full Color Outdoor Fixed LED Display P4 P6.67 P8 P10 For Railway Station Shopping Mall 3



Full Color Outdoor Fixed LED Display P4 P6.67 P8 P10 For Railway Station Shopping Mall 4



Full Color Outdoor Fixed LED Display P4 P6.67 P8 P10 For Railway Station Shopping Mall 5



Full Color Outdoor Fixed LED Display P4 P6.67 P8 P10 For Railway Station Shopping Mall 6





Why Choose Us?
1. 10 years experience of led display, CE, RoHS, FCC, C-Tick and ISO9001:2008 approved.

2. Quality test report for every order.
3. Free technician training.
4. Strict quality control from the raw material test to manufacturing, assembly and aging test;
5. Fast response and professional service, suggestions and solutions, special design and free lifelong consultation for you.

6. Special service for big project, such as stadium, exhibitions, squares and so on.
7.All products 24 months warranty and provides lifelong maintenance with free labor and service only charging raw materials with reasonable price.

Full Color Outdoor Fixed LED Display P4 P6.67 P8 P10 For Railway Station Shopping Mall 7

FAQ:
Q1. Are you trading company or manufacturer?
A: We are a professional led screen manufacturer.
Q2. What is your terms of payment?
A: T/T or Western Union 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. Do you provide samples ? is it free or extra?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q4. How about your delivery time?
A: Generally, sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than.
Q5. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q6. Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
Q8: How can I get technology support?
A:1.We will train in our factory and send video for showing. The training include system use, system maintenance and equipment protection.

Full Color Outdoor Fixed LED Display P4 P6.67 P8 P10 For Railway Station Shopping Mall 8



Full Color Outdoor Fixed LED Display P4 P6.67 P8 P10 For Railway Station Shopping Mall 9
