Product Details:
Payment & Shipping Terms:
|
| Physical Pitch: | 6.67mm | Pixel Density: | 22,500 Pixels/m² |
|---|---|---|---|
| Panel Dimensions: | 1280 X 960 | Refresh Rate: | >1920Hz |
| Brightness: | >6500nits | Contrast Ratio: | 2000:1 |
| High Light: | roadside led display,outdoor waterproof led advertising panels |
||
Outdoor LED Advertising Display 6.67mm Pixels Front Service 8 Scan Energy Saving Panel
Quick Details:
1, Pixel Pitch: 4.81/6.67/8 mm.
2, Full colors: 281trillions.
3, SMD, Wide viewing angle: 160°/ 140°.
4, Standard cabinet size: 1280×960 mm, weight: 60kg for steel frame.
5, Recommended minimum viewing distance: 6m.
6, Warranty: 2years.
Specification
|
Pixel Pitch |
P4.81 |
P6.67 |
P8 |
P10 |
|
LED Type |
SMD2727 |
SMD2727 |
SMD3535 |
SMD3535 |
|
Module Size |
250*250 |
320*320 |
256*256 |
320*320 |
|
Cabinet Size |
1000*1000*150 |
1280*960*150 |
1280*768*150 |
1280*960*150 |
|
Module Resolution |
52*52 |
48*48 |
32*32 |
32*32 |
|
Cabinet Weight |
65/45kg |
|||
|
Cabinet Material |
Steel/ Aluminum |
|||
|
Gray Scale |
16 bit |
|||
|
Contrast Ratio |
2000:1 |
|||
|
View Angle(H/V) |
160°/ 140° |
|||
|
Refresh Rate |
＞1920Hz |
|||
|
Brightness |
＞6500nits |
|||
|
IP Rating |
IP65 / IP54 |
|||
|
Servicing |
Front / Rear |
|||
|
Operating Temp/Humidity |
-20℃-50℃ / 10%-90% |
|||
|
Expected Lifetime |
100,000Hrs |
|||
|
Average Power Consumption |
360W/ Panel |
|||
Introduction:
Outdoor Rated
● IP65 rating for front and rear
● Suitable brightness adjustable for outdoor day and night
● Strong and high bright LED
Intelligent Software System
● Intelligent control and player system by cloud technology
● Time management and real time monitoring
Installation:
Company Introduction:
BAKO VISION product lines have include UHD fine pitch, I/O rental, I/O fixed install, transparent screen, advertising poster, foldable screen, flexible screen, curtain, floor LED, perimeter display… meanwhile, based on our experienced R&D team and comprehensive management, we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.
FAQ
1. How to payment?
We accept the L/C, T/T.
2.What is the packing method?
We usually use plywood case or flight case.
3.How about the delivery time?
We will ship within 15-25 working days after you placed the order.
4.What's the warranty of your Screen?
We have a 2-year warranty for our led display screen, and 100,000 hours life span of the led lamps
