P10 Outdoor Waterproof Fixed Led Billboard, Led digital Display TV Wall for Building Advertising and Street AD
Led Billboard Quick Details:
1, Pixel Pitch: 10mm.
2, Full colors: 281trillions.
3, SMD, Wide viewing angle: 160°/ 140°.
4, Standard cabinet size: 960×960x150mm, The size can be customized.
5, Recommended minimum viewing distance: 10m.
6, Warranty: 2years.
Led Billboard Description:
Bako Vision outdoor led digital billboards pixel include 4.81mm, 6.67mm, 8mm,10mm,15mm. It can use in lots of space, such as shop mall, outdoor adverting, building roof etc. Even you can use it on car as mobile screen.
Led Billboard Features and Advantages:
1, High brightness from 6,500nits to 9,000nits, visible from every direction even face to direct sunshine.
2, SMD LEDs ensure large viewing angle, up to 160° horizontally and 140° vertically.
Image no distortion, no color cast in any angle within this range.
3, Cabinet design lightweight, side handle for easy carrying and assemble job.
4, IP65 waterproof and dust resistance, durable for any weather condition.
5, Meanwell brand power supply, saving energy and high efficiency.
6, Digital process: 16bits, contrast ratio 2,000:1, vivid color.
7, Front access make easy maintenance.
8, There can improve the resolution by changing new module with small pixel, no need to purchase new screem,this can save lot of cost.
Led Billboard Specification:
||10,000 pixels/Square Meter
|Module Dimensions(W x H) (mm)
||320 x 320
|Panel Dimensions (mm)
||1280 x 960 x 150
|Physical Resolution of Panel (W x H)
||128 x 96
||Steal / Aluminum
||2,000 : 1
|Average Power Consumption
||360 W /panel
|Max Power Consumption
||900 W /panel
||Front / Rear
|IP Rating (Front/Rear)
||IP 65 / IP 54
||-20ºC - 50ºC / 10ºC - 90ºC
||-20ºC - 50ºC / 10ºC - 90ºC
Led Billboard Case;
1.We guaratee all our display, modules, spare parts for TWO years.
2.We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
3.After warranty, we also can offer you the parts for replacement at our bottom price.
4.After sales, if you have any problem about our product, you can inform us by E-mail, we will reply you at once
when we get it and offer you a good solution to solve the problem.
5.We also could solve problems for you antil it recovers well by remote control!
1.Delivery time, Accompalish manufacturing within 25 days after receiving the deposit.
2.Before Delivery, we will test the display , and keep it light up for 72 hours, and check all the parts of the display to confirm it is OK for delivery.
1.We can assist the training and technical support for the customer in the factory, if the customer require so.
2.We could send our engineer to guide the installation to you. But the relavant cost should be paid by your esteemed company.
3.Our technicians will offer CAD Drawing to show how to install the LED Display rightly and fast,
