Outdoor Fixed Commercial LED Billboard, Full Color P10 Back Service SMD LED Panel
Product Details
| Panel Material: | Steel/Aluminum | Brightness: | >6,000 Nits |
|---|---|---|---|
| Servicing: | Rear | IP Rating(Front/Rear): | IP65/IP54 |
| Refresh Rate: | >1,920 Hz | Processing: | 16 Bit |
| Highlight |
roadside led display,street led screen |
||
Product Description
Outdoor Fixed Commercial LED Billboard, Full Color P10 Back Service SMD LED Panel
Products Description
Energy-Saving Technology
Cutting edge “cold display” technology
60% power lower than normal
50% tempearture less than normal
Specification
| BOF-B-3 | BOF-B-4 | BOF-B-5 | BOF-B-6 | BOF-B-8 | |
| Pixel Pitch | 3.2mm | 4mm | 5mm | 6.67mm | 8mm |
| Pixel Configuration | SMD1921 | SMD1818 | SMD2727 | SMD2727 | SMD3535 |
| Pixel Density | 97,656 pixels/m² | 62,500pixels/m² | 40,000pixels/m² | 22,376 pixels/m² | 15,625 pixels/m² |
| Module Size | 192*192 | 320*160 | 320*160 | 320*160 | 320*160 |
| Panel Size | 960*960*150 | 960*960*150 | 960*960*150 | 960*960*150 | 960*960*150 |
| Panel Resolution | 300*300 | 240*240 | 192*192 | 144*144 | 120*120 |
| Panel Material | Steel/Aluminum | Steel/Aluminum | Steel/Aluminum | Steel/Aluminum | Steel/Aluminum |
| Weight(sqm) | 65/45 | 65/45 | 65/45 | 65/45 | 65/45 |
| Contrast Ratio | 2000:1 | 2000:1 | 2000:1 | 2000:1 | 2000:1 |
| Brightness | 6500 nits | 6500 nits | 6500 nits | 6500 nits | 6500 nits |
| Refresh Rate | 1920 Hz | 1920 Hz | 1920 Hz | 1920 Hz | 1920 Hz |
| IP Rating | IP 65 | IP 65 | IP 65 | IP 65 | IP 65 |
| Scan Method | 1/16 Scan | 1/8 Scan | 1/8 Scan | 1/10 Scan | 1/4 Scan |
Features
Durable and Qualified Components
The most durable and qualified components are selected
Deliberate designs on waterproof and ventilation system
Fast Installation and Easy Maintenance
Fast lock system guarantees a quick and easy installation
Conventional Rear access
Outdoor Rated
IP65 rating Brightness adjustable for day and night
Selected LED for 7/24 work mode
Packaging and Shipping
Cases:
About Us
LED Vision Technology Limited , started in Shenzhen in 2005, a world class manufacturer of technologically advanced LED displays, focusing on high end professional customers among domestic and overseas markets. BAKOVISION is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.
BAKO VISION contains of experienced team leaders and each of them has been working in LED display industry over 10 years. All of our R&D, Production, Sales, Technical Support depts….are running efficiently and smoothly by our great team work, moreover, delivering qualified product and offering timely pre-after service are also assured by BAKO VISION team.
BAKO VISION product lines have include UHD fine pitch, I/O rental, I/O fixed install, transparent screen, advertising poster, foldable screen, flexible screen, curtain, floor LED, perimeter display… meanwhile, based on our experienced R&D team and comprehensive management, we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.
BAKO VISION main markets are among America, Europe, Middle East and Asia, all of our products are certificated by RoHS,CCC,CE,FCC,ETL,UL. Standing firmly by quality, winning firmly by proficient, in the past years of development, BAKO VISION continuous growth and brand positioning are all relied onto the long term partnership with variety channel customers over 120+ countries.
Our Advantages
Rich experience: established in 2005; familiar with technical and material about LED display.
Absolute OEM service: providing the most suitable solution for you according to your different demands (such as quality, price and etc.). At least 3 different types in one material are provided for your choice , and with the lowest-cost custom service.
Powerful R&D ability: excellent engineers are constantly developing new products and improving them.
Good quality:All products have passed CE, ROHS, FCC certification.
Thoughtful service: we always serve you heart and soul, striving to make our products meet your demands in maximum degree.
We guarantee all our LED products for 2 years and provide lifetime maintenance charging only for raw materials. We provide an excellent after-sale service, which contains free training, free CAD drawings, for more convenience and free consultation lifetime.
