Product Details:
Payment & Shipping Terms:
|
| Pixel Configuration: | SMD 2727 | Control Way: | Synchronous Or Asynchronous |
|---|---|---|---|
| Power Supply: | Meanwell Or Customized | Module Demensions (W*H)(mm): | 320*320 |
| Control System: | WiFi / 3G / 4G | Driver IC: | MBI 5124 |
| Operating Temp / Humidity: | -20ºC-50ºC/10%-90% | Matching System: | Nova Star, Linsn |
| Refresh Rate: | >1920 Hz | Customized Design: | OEM / ODM |
| High Light: | roadside led display,street led screen |
||
P6 Outdoor HD Digital Billboard Conventional LED for Advertising Panel Screen
Features of LED Billboards.
1. High resolution: The most apparent features of the new generation of LED display.
2.Good color uniformity:With brand Lamp Nationstar and high refresh MBI5124 IC..
3.Easy maintenance: After adopting the classic back maintenance,it's applied to large size LED and roof mounting,wall mounting and pillar base.
4. High intensity and can be adjusted, so can meet the request of the customers according to the application environment.
5.Long-term Brightness:6000-nit brightness(for outdoor full color) throughout product lifetime of the LED display.
6. 100% Waterproof LED module: 100% waterproof module design,protection level IP65,PCS connections replace the
traditional electronic line which is safe and reliable.
Specifications
| BOF-6 | |
| Physical Pitch | 6.67mm |
| Pixel Configuration | SMD 2727 |
| Pixel Density | 22,500 pixels/m² |
| Module Dimensions(W*H)(mm) | 320*320 |
| Panel Dimensions(mm) | 1280*960*150 |
| NO. of Modules Per Panel (W*H) | 4*3 |
| Physical Resolution of Module (W*H) | 48*48 |
| Physical Resolution of Panel (W*H) | 192*144 |
| Panel Material | Steel/ Aluminum |
| Colors | 281 trillion |
| Brightness | >6,500 nits |
| Weight (kg/m²) | 65/45 |
| Processing | 16 bit |
| Refresh Rate | >1920 Hz |
| IP Rating | IP65/ IP54 |
| Viewing Angle | V:160 degree H: 140 degree |
| Expected Lifetime | 100,000 Hrs |
| Operating Temp/Humidity | -20ºC-50ºC/ 10%-90% |
| Storage Temp/Humidity | -20ºC-50ºC/ 10%-90% |
| Avg./ Max. Power Consumption | 360/900W/ panel |
| Servicing | Front/Rear |
Procesure Details
Big viewing angle to 140 degree at horizontal line, 140 degree at vertical line, you can see at every angle, at this range, no picture change, no color excursion
The related accessories
3. Multiple installation methods
Applications:
Ideal for dazzling different events, such as Stage, Concert, Fashion Show, Wedding, Conference, Building, Hotel, Club & Bars, Festival, etc.
