Product Details:
Payment & Shipping Terms:
|
| Material: | Die-Casting Aluminum | Light: | Nationstar |
|---|---|---|---|
| Driver IC: | MBI5124 | Usage: | Indoor |
| Warranty: | 2 Years | Power Supply: | Meanwell |
| High Light: | modular led display,shopping mall led display |
||
Front-service P1.2 Indoor Hd Led Video Wall with Nationstar leds For TV Station
P1.2 HD Led Display Description:
1. Invisible line design
2. 2pc handles each cabinets, convenient to take it out
3. No need to reserve the maintenance channel behind the cabinet, and install against the walls(save space)
4.16:9 pixel to pixel restore high definition
5.Each cabinet only 6kg , slim 60mm
6.Quick lock fastly assmble/dismantle, save labour cost
P1.2 HD Led Display Specs:
| Pixel Pitch | UHD-1.2 | UHD-1.5 | UHD-1.8 | UHD-2.3 |
| LED Type | SMD black LED | |||
| Module Size | 150mm*168mm | |||
| Cabinet Size | 600mm*337mm | |||
| Module Resolution | 120*135 | 96*108 | 80*90 | 64*72 |
| Cabinet Weight | 6kg | |||
| Cabinet Material | Die-Casting Aluminum | |||
| Gray Scale | 16bit | |||
| Contrast Ratio | 4000:1 | |||
| Brightness | 600-800cd/㎡ | |||
| View Angle(H/V) | 160°/140° | |||
| Refresh Rate | 1920Hz | |||
| IP Rating | IP40/IP21 | |||
| Optimal Viewing Distance | 1.5m | 1.9m | 2.3m | 2.9m |
| Average Power Consumption(W/㎡) | 300 | |||
| Maximum Power Consumption(W/㎡) | 600 | |||
| Operating voltage | 110~220V AC,50/60HZ | |||
P1.2 HD Led Display Features:
