IP65 Waterproof Outdoor Fixed LED Display High Brightness Fixed Installation
Product Details
| Pixel Pitch: | 8mm | LED Type: | SMD 3 In 1 |
|---|---|---|---|
| Brightness: | ≥5500nits | Weight: | 65/45KG |
| Servicing: | Front / Rear | IP Rating(Front/Rear): | IP65/IP54 |
| Average Power Consumption: | 350W/m² | Panel Material: | Steel/ Aluminum |
| Highlight |
roadside led display,outdoor waterproof led advertising panels |
||
Product Description
IP65 High Brightness Outdoor LED Display Screen Fixed Installation
Features:
1. Nationstar LEDs, long lifetime with high brightness 6,500nits, visible from every direction even face to sunshine directly.
2. SMD technology, LEDs ensure a large viewing angle, up to 160° horizontally and 140° vertically.
Image no distortion, no color cast in any angle within this range.
3. Cabinet design lightweight, side handle for easy carrying and assemble job.
4. IP65 waterproof and dust resistance, durable for any weather conditions.
5. Meanwell brand power supply, saving energy and high efficiency.
6. Digital process: 16bits, contrast ratio 2,000:1, vivid color.
7. Front access makes easy maintenance.
8. There can improve the resolution by changing new module with a smaller pixel, no need to purchase a new screen, this can save lots of costs.
Specifications:
| Pixel Pitch | P4.81 | P6.67 | P8 | P10 |
| LED Type | SMD2727 | SMD2727 | SMD3535 | SMD3535 |
| Module Size(mm) | 250x250 | 320x320 | 256x256 | 320x320 |
| Panel Size(mm) | 1000x1000x150 | 1280x960x150 | 1280x768x150 | 1280x960x150 |
| Module Resolution(WXH) | 52x52 | 48x48 | 32x32 | 32x32 |
| Cabinet Weight | 65/45kg | |||
| Cabinet Material | Steel/ Aluminum | |||
| Gray Scale | 16 bit | |||
| Contrast Ratio | 2000:1 | |||
| View Angle(H/V) | 160°/ 140° | |||
| Refresh Rate | >1920Hz | |||
| Brightness | >6500nits | |||
| IP Rating | IP65 / IP54 | |||
| Servicing | Front / Rear | |||
| Operating Temp/Humidity | -20ºC-50ºC / 10%-90% | |||
| Expected Lifetime | 100,000Hrs | |||
| Power Consumption | Average: 360W/ Panel, Max: 900W/Panel | |||
FAQ:
Q1. Are you trading company or manufacturer?
A: We are a professional led display manufacturer OVER FOURTEEN YEARS.
Q2. What's your payment term?
A: T/T, Western Union, L/C
Q3. Do you provide samples ? is it free?
A: We can supply the sample if we have ready parts in stock
but the customers have to pay the sample cost and the courier cost.
Q4. How about your delivery time?
A: Generally, the sample needs 5-7 days, 15-25 working days for batch order.
Q5. How do you ship the goods and how long does it take to arrive?
A: We usually ship goods by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Air Freight and sea shipping are also optional.
Q6. Do you offer a guarantee for the products?
A: Yes, we offer 2 years warranty for our products, we have a warehouse in the USA and our engineer stay in the USA to deal with after-sales and provide technical support.
Q7: How can I get technical support?
A: We will train in our factory and send video for showing. The training includes system use, system maintenance, and equipment protection. We often attend exhibitions around the world every year
so we can visit you if you need at that time.
