| Foldable Angle: | 360° | Servicing: | Front Maintenance |
|---|---|---|---|
| Contrast Ratio: | 2,000:1/4,000:1 | Expected Lifetime: | 100,000Hrs |
| Usage: | Indoor | Warranty: | 3~5 Years |
| High Light: | flexible led curtain display,foldable led screen |
||
Flexible LED Display 360° Foldable P10 SMD3528 Front Servicing Easy Connection (BF.pdf)
Flexible LED Display Specifications
| BF-6 | BF-7 | BF-10 | BF-12 | |
| Physical Pitch | 6mm | 7.8mm | 10mm | 12mm |
| Pixel Configuration | SMD3528 | SMD3528/SMD3535 | SMD3528 | SMD3528 |
| Pixel Density | 27,556 pixels/sqm | 16,384 pixels/sqm | 10,000 pixels/sqm | 6,889 pixels/sqm |
| United Size(mm) | 192*192 | 250*250 | 160*160 | 192*192 |
| Physical Resolution of Unit(W*H) | 32*32 | 32*32 | 16*16 | 16*16 |
| Weight(kg/sqm) | <10 | <9 | <9 | <9 |
| Processing | 16 bit | 16 bit | 16 bit | 16 bit |
| Colours | 281trillion | 281trillion | 281trillion | 281trillion |
| Contrst Ratio | 2,000:1/4,000:1 | 2,000:1/4,000:1 | 2,000:1/4,000:1 | 2,000:1/4,000:1 |
| Average Power Consumption | 150/310W/sqm | 90/200W/sqm | 110W/sqm | 75W/sqm |
| Max Power Consumption | 375/775W/sqm | 225/500W/sqm | 275W/sqm | 187W/sqm |
| Refresh Rate | >1,920Hz | >1,920Hz | >1,920Hz | >1,920Hz |
| Brightness | 2,000/4,000nits | 1,500/6,000nits | 1,500nits | 1,500nits |
| Flodable Angle | 360° | 360° | 360° | 360° |
| Max Length of Control Box | 6m | 8m | 4m | 12m |
| Servicing | Front | Front | Front | Front |
| IP Rating(Front/Rear) | IP43/IP54 | IP43/IP54 | IP43/IP54 | IP43/IP54 |
360° Foldable LED Panel Features
Variable Flodable Module
►180 or 360 degree foldable
►Convenience:saving the storage and transpotation cost,also saving the space.
Slim,Light Weight and Quiet
►8.5mm-15mm thickness
►<12kg per ㎡,easy to move and carry
►Extended Data and Power Box,integrated unit
►Max power cable distance 7m-10m
Easy and fast Installation
►Available for both horozontal and vertical assembling
►Flat and curve options for any customized installation
►Easy connection design allows the fast set up and tear down,save 80% labor cost
Packaing and Shipping
Our Advantages
1. Rich experience: established in 2005; familiar with technical and material about LED display.
2. Absolute OEM service: providing the most suitable solution for you according to your different demands (such as quality, price and etc.).
3. At least 3 different types in one material are provided for your choice , and with the lowest-cost custom service.
4. Powerful R&D ability: excellent engineers are constantly developing new products and improving them.
5. Good quality:All products have passed CE, ROHS, FCC certification.
6. Thoughtful service: we always serve you heart and soul, striving to make our products meet your demands in maximum degree.
7. We guarantee all our LED products for 2 years and provide lifetime maintenance charging only for raw materials.
8. We provide an excellent after-sale service, which contains free training, free CAD drawings, for more convenience and free consultation lifetime.
FAQ:
Q1: The warranty of your LED Display Board ?
A: We offer 2-3 year warranty for our different led display screen series, 100,000 hours life span for the led lamps, and lifetime technology support with 7/24 phone answering service if you have any problem with our led screen.
Q2: Whats your payment term? How long it takes to delivery?
A: We normally accept T/T and L/C,and other payment options is negotiable for your convenience. A 30% deposit is needed in advance, and the rest 70% be paid before delivery. Our average lead time is 15 days.
Q3: What's the controlling system?
A: Our standard controlling system for this model is Novastar. Also support other controlling system such as Linsn, etc.
