Product Details:
Payment & Shipping Terms:
|
| Grey Scale: | 14bit | Cabinet Resolution: | 192*160pixels |
|---|---|---|---|
| Colours: | 281trillion | IP Rating (Front/Rear): | IP65/IP54 |
| Driving Method: | 1/6 Scan | Single Cabinet Weight: | 27.7kg |
| High Light: | roadside led display,street led screen |
||
P3.2 Rear Service High Brightness Outdoor Fixed LED Display Full-ColorLED Signage
Important knowledge of LED displays
1. What is LED?
LED is sanded for light emitting diode, a kind of semiconductor which is used to give and receive the electronic signal into infrared rays or light, using the characteristics of compound semiconductor. This is used for household appliances, remote controller, electric bulletin board, various kinds of automation appliances.
2. What are pixel pitch, pixel density, LED QTY and pixel configuration?
Pixel pitch is the distance between neighboring pixels.
Pixel density is the quantity of pixels per square meter.
LED qty is the quantity of LED lamps per square.
Pixel configuration is the description of the consistence of a pixel, for instance, we use 1 red lamp, 1 green lamp, and 1 blue lamp to compose a pixel, the pixel configuration is 1R1G1B.
3. What are LED type, module size and module resolution?
LED type is the description of LED lamp, for instance, the brand, the shape in physical, the size of the lamp
Module size is the measurement of a module.
Module resolution is the number of pixels per module.
| Pixel pitch | 3.2mm |
| Pixel density(dots/m2) | 97656 |
| LED encapsulation | SMD 1617 |
| Module size(mm) | 512*256 |
| Cabinet weight (Kg) | 27.7 |
| Cabinet size(mm) | 1024*768 |
| Brightness (nits) | ≥5000 |
| Refresh rate | ≥960 Hz |
| Grey scale | 13 bit |
| Protection grade | IP65/IP54 |
| Service | Rear |
1. Light Weight & Pretty Thin
Made by excellent aluminum material, each panel only weights 8KG which makes installation job and
delivery be much more comfortable and convenient. Pretty thin, thickness 95m m not only saves delivery
space but also saves installation space.
2. High brightness & Waterproof
Brightness up to 5,500nits, IP65 waterproof level. It provides a perfect solution for outdoor stage use.
3. Fast Lock System & Natural Cooling System Design
Fast lock system enables installation and dismantle to be much faster: an average worker can finish 50- 70 panels per hour. Natural cool system design results in good heat dissipation and less power
Aging Testing
LED display aging test precautions
1. The test content: black and white, red, green, blue monochrome, grayscale gradient, video effects, text effects
2. LED display a white screen test playing time is not less than 24 hours
3. Monochrome and grayscale gradient test not less than 24 hours
4. Video and text effects test not less than 24 hours
After-sales service
1. Service principles: response in time, solve problems as soon as possible and ensure the use.
2 .Service period: In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.
3. Service scope: If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.
4. Under normal use and storage, Our Company will be responsible for the equipment.
