Product Details:
Payment & Shipping Terms:
|
Driving Method: | Constant Current | MTBF: | ≥1000 Hours |
---|---|---|---|
Control System: | USB/LAN/WIFI/GPRS/3G/4G | Certification: | UL,CE,ROHS EMC |
Screen Size: | 960*1920mm | Screen Resolution (W*H): | 192*384 |
Pixel Pitch: | 5mm | Pixel Configuration: | 1R1G1B |
Highlight: | led poster display,mirror led display |
P5 Smart Digital Indoor LED Poster Wide View Angle High Brightness and Greyscale RGB for Advertising
Product features:
You can enjoy good visual effect due to its high definition and greyscale.
You can achieve the synchronous and asynchronous control with WIFI, 3G/4G wireless control.
Quick installation, simple operation and convenient maintenance save the cost greatly.
Features:
This product is widely used in shopping malls, restaurants, airports, hospitals, gas stations, shops and other indoor places.
The product can be connected to multiple network modes and supports remote office control.
You can set its playback content in advance , which is easy to operate.
The brightness can be adjusted according to different environment .
Why Choose LED?
Specification:
Model | IAD-5 |
Pixel Pitch | 5mm |
Pixel Configuration | 1R1G1B |
LED Type | SMD2121 |
Module Size | 160*160 |
Screen Size | 960*1920mm |
Screen Resolution (W*H) | 192*384 |
Frame Size | 1060*2320*95mm |
Frame Material | Aluminum frame |
Base Material | Steel base |
Cover Material | Armored glass |
Weight | 175kg |
Brightness | >1200nits |
Driving Method | Constant current |
Scanning | 1/16 Scan |
View Angle(H/V) | 140°/140° |
Viewing Distance | ≥5m |
Power consumption(Max.) | 1080w |
Power Supply | AC 110/220±10% 50~60Hz |
MTBF | ≥1000 Hours |
Earth Leakage Current | <1.5mA |
Storage Temperature | -40℃ ~ +85℃ |
Operating Temperature | -30℃ ~ +60℃ |
Operating Humidity | 10%~75% |
Control System | USB/LAN/WIFI/GPRS/3G/4G |
Certification | UL,CE,ROHS EMC |
