Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 6.67mm | Pixel Density: | 22478 Pixels/m2 |
|---|---|---|---|
| LED Type: | SMD3535 | Cabinet Dimension: | 640mmx640mm |
| Cabinet Resolution: | 96*96pixels | Brightness: | >6500nits |
| Viewing Angle(H/V): | 140°/140° | Driving Method: | 1/6 Scan |
| High Light: | led screen stage backdrop,stage background led screen |
||
P6.67 6.67mm Outdoor Stage Rental LED Display Light Weight Cabinet Die Casting Aluminum
HD rental full color led display:
1. Highcontrast mask design: new antiglare mask design, fine sand processing and black coating on the surface, no glare, and improve the contrast.
2. Automatic SMT: adopting highend automatic SMT machine, advanced wave soldering and reflow soldering processing, to effectively avoid the wrong plug, plug leakage, leakage welding, virtual welding problems.
3. Module suite: improve the planeness of the whole screen, and reduce the seam between the neighboring modules.
4. Multi gray display: adopting 16bit gray processing technology to restore the natural image. And using S-PWM driving technology to add gray grade, meet the 16bits high gray display requirements with low brightness.
5. Point by point correction: the correction technology of brightness and chromaticity to ensure the uniformity of led screen’s brightness and color.
Variety and easiness
1. Various installation: cabinet assembly or magnetic suction installation
2. Easy maintenance: optional front maintenance, back maintenance and single point maintenance according to the installation site.
3. High contrast mask design
Specification
| Model | ORB-6.67 |
| Pixel Pitch | 6.67mm |
| Pixel Density | 22478 pixels/m2 |
| LED Type | SMD3535 |
| LED Configuration | 1R1G1B |
| Cabinet Dimension | 640mmx640mm |
| Cabinet Resolution | 96*96pixels |
| Cabinet Weight | 13kg |
| Cabinet Material | die casting aluminum |
| Ingress Protection(front/rear) | IP65/IP54 |
| Brightness | >6500nits |
| Viewing Angle(H/V) | 140°/140° |
| Driving Method | 1/6 Scan |
| Frame Refresh | ≥ 60Hz |
| Data Refresh Rate | >1500Hz |
| Gray Scale | 16bit |
| Power Consumption(avg.) | 300w/m2 |
| Input Voltage | AC 110/220±10%, 50~60Hz |
| Temperature(operating/storage) | -20~50°C / -40~60°C |
| Humidity(operating/storage) | 10%~90%RH / 10%~85%RH |
| MTBF | ≥1000hrs |
| Life Span | ≥100000hrs |
| Pixel Failure | <0.0003 |
Excellent After-sale Service
1.Warranty will be valid for 24 months against manufacturing defect.
2.The warranty shall not apply to the following circumstances:
a) Damage caused by undue ware& tear, misuse, improper installation or operation, neglect, accidents.
b) Damage caused by natural disasters, flood fire, lightning or pollution.
c) If item was opened, any parts removed or repaired by any unauthorized person.
