Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 8mm | Pixel Density: | 15625 Pixels/m2 |
|---|---|---|---|
| LED Type: | SMD3535 | Cabinet Dimension: | 1024mm*768mm |
| Cabinet Resolution: | 128*96pixels | Cabinet Weight: | 51kg |
| Driving Method: | 1/8 Scan | ||
| High Light: | outdoor led billboard,outdoor electronic signage boards |
||
Pixel Pitch 8mm Outdoor Billboard LED Display,Fixed High Resolution Panel Wall
Description
There are low weight.Both module frame and cabinet can be made of die-casting aluminum,much reducing the screen weight.Both Front and Rear service.Good heat dissipation;No matter for cabinet or for module frames,they are both die-casting aluminum,making sure of good heat dissipation.So screen can still work well in high temperature.
Advantage
1. High brightness more than 6500 nits with automatic brightness adjustment
2. Best quality LED lamps ensures wide color range, excellent color uniformity, no rainbow effect, broadcasting strong stability
3. High grey level and high refresh rate,obtain ultimate visual impact even under solar direct radiation, natural performance
4. Low power consumption, metal cooling structure,noise-free, long life span
5. High level of water-proof and dust-proof (frontIP 65/ rear IP 54), adapt to extreme heavy weather
6. Support front and rear maintenance, savinghuman cost.
7. Wirless control system optional .No need computer,very convenient. It can be used as synchronous control system too.
Pre-sale service
1. Reply inquiries in 24 hours.
2. Provide professional suggestion and solutions based on customer's requirement.
3. Offer sample and all document as customers required.
4. Other services, such as factory visit and so on.
In-sale service
1. Tracking report of production.
2. Quality test report for every order.
3. Photos and videos in the production.
After-sale service
1. Lifetime maintenance and software upgrade.
2. Complaint respond period not exceed 24 hours, maintenance guidance and problem solution supplied in 48 hours.
3. Free technician training.
4. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
5. Engineer guide installation at site if needed.
| Model | OD-8 |
| Pixel Pitch | 8mm |
| Pixel Density | 15625 pixels/m2 |
| LED Type | SMD3535 |
| LED Configuration | 1R1G1B |
| Cabinet Dimension | 1024mm*768mm |
| Cabinet Resolution | 128*96pixels |
| Cabinet Weight | 51kg |
| Cabinet Material | cold steel |
| Ingress Protection (front/rear) |
IP65/IP54 |
| Brightness | >6500nits |
| Viewing Angle(H/V) | 140°/140° |
| Driving Method | 1/8 scan |
| Frame Refresh | ≥ 60Hz |
| Data Refresh Rate | >1500Hz |
| Gray Scale | 16bit |
| Power Consumption(avg.) | 275w/m2 |
| Input Voltage | AC 110/220±10% 50~60Hz |
| Temperature (operating/storage) |
-20~50°C / -40~60°C |
| Humidity(operating/storage) | 10%~90%RH / 10%~85%RH |
| MTBF | ≥1000hrs |
| Life Span | ≥100000hrs |
| Pixel Failure | <0.0003 |
