Modular LED Displays Indoor Event Video Wall For Events Fairs And Conferences

Modular LED Displays Indoor Event Video Wall For Events Fairs And Conferences
Modular LED Displays Indoor Event Video Wall For Events Fairs And Conferences

Large Image :  Modular LED Displays Indoor Event Video Wall For Events Fairs And Conferences

Product Details:

Place of Origin: China
Brand Name: Bako
Certification: CCC, CE, ETL, FCC
Model Number: BIR Series

Payment & Shipping Terms:

Minimum Order Quantity: 1 sqm
Price: Negotiation
Packaging Details: Flight case/Plywood case
Delivery Time: 15-20 working days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 8,000㎡ per month
Detailed Product Description
Product Name: Rental LED Panel Pixels: 2.97mm/3.91mm/4.81mm
Cabinet Size: 500x500x80mm/500x1000x80mm Cabinet Materials: Die-casting Aluminum
Cabinet Weight: 7 / 13 Kgs/cabinet Brightness: 900-1,200 Nits
Pixel Density: 65,536 Pixels/㎡ Refresh Rate: >1,920 Hz
Life Span: 100,000hours Warranty: 2 Years
High Light:

1200 nits Modular LED Displays

,

900 nits Modular LED Displays

,

1200 nits Event Video Wall



Modular LED Displays Event Video Wall Indoor Rental LED Screens For Events Fairs And Conferences



Here at Bako Vision Display we know the problems of indoor rental applications and the importance of having versatile, lightweight, easy to carry and fast installation products. In the last years, we have been focusing on selecting products with high performance features and at the same time ensuring an ideal relationship between performance, quality of materials and price.


Modular LED Screens Parameters



  BIR-I-2 BIR-I-3 BIR-I-4
Physical Pitch 2.97mm 3.91mm 4.81mm
Pixel Configuration SMD2121 SMD2121 SMD2121
Pixel Density 112,896 pixels/m² 65,536 pixels/m² 43,264 pixels/m²
Module Dimensions 250*250mm/250*500mm 250*250mm/250*500mm 250*250mm/250*500mm
Panel Dimensions 500*500*80mm/500*1000*80mm 500*500*80mm/500*1000*80mm 500*500*80mm/500*1000*80mm
Physical Resolution of Panel 168*168dots/168*336dots 128*128dots/128*256dots 104*104dots/104*208dots
Panel Material Die-Casting Aluminum Die-Casting Aluminum Die-Casting Aluminum
Single Cabinet Weight 8kg 8kg 8kg
Grayscale 16bit 16bit 16bit
Colors 281trillion 281trillion 281trillion
Contrast Ratio 4000:1 4000:1 4000:1
Average Power Consumption 60/120W/ panel 60/120W/ panel 60/120W/ panel
Max Power Consumption 110/400 W/ panel 110/400 W/ panel 110/400 W/ panel
Refresh Rate >1920Hz >1920Hz >1920Hz
Brightness 900 - 1200 nits 900 - 1200 nits 900 - 1200 nits
Expected Lifetime 100,000Hrs 100,000Hrs 100,000Hrs
Servicing Front/Rear Front/Rear Front/Rear
IP Rating(Front/Rear) IP40/IP21 IP40/IP21 IP40/IP21







Stage LED Screens Descriptions



1. Indoor events typically want to use indoor LED panels, as they are less bright yet generally have a smaller pixel pitch.



2. Outdoor events typically use indoor/outdoor LED panels, which are brighter yet general have a larger pixel pitch than indoor panels.



3. Can be built any shape or size since they are constructed of individual panels you can stack them so they are very tall or really wide.



4. There are several variables that go into setup time, with screen size and mounting structure being the most significant factors.



5. Where pricing is concerned modular screens will be much closer to the price of a mobile screen when the event goes multiple days.



6. We offer 5mm, 6mm, 7mm and new high resolution 9mm pixel pitch LED Screens for a great balance of resolution and price.







Indoor Video Wall Options

Modular LED Displays Indoor Event Video Wall For Events Fairs And Conferences 0



Ground stacked, rear supported is a common choice for those using their screen as a backdrop. With this option the screen can only be off the floor 2 feet at most. If you are concerned about seeing the structure this is a desirable option as the audience will not be able to see it from where they are sitting.



Stage stacked affixed to scaffolding is a great option if you’re going to be outside. It’s much safer than a flown screen because these can be dangerous to set up in windy conditions. With this set up the screen can be from 2 to 7 feet off the ground. Many people prefer the aesthetics of this option because you can drape the scaffolding, making it more visually appealing.



Flown off of a truss is great if you need to get your screen as high as 10 feet in the air. This set up is also quicker than using a scaffold because it uses motors to bring the screen into place. The aesthetics of this installation is dependent on tastes. Some people like it, while others don’t. It’s also important to remember that this is not a great option if you are expecting heavy wind as the screen is hanging from the truss so it can move freely in the wind and cause problems.



Flown off of a forklift is also a great option for getting your screen 8 feet in the air or higher. Most people don’t like the look of the forklift and so choose to go with the truss supported screen. The installation is done by securing a piece truss to the forks and building the screen from there. This is the simplest way to get a screen high in the air while not the most attractive.



While it’s important to understand your options, our screen providers will give you their recommendation with your needs and budget in mind. They will be able to give you the best option while considering all safety precautions necessary.



Pricing Considerations



In most cases modular screens will be more expensive than mobile screens (when comparing equal screen sizes). For shorter events modular screens may not be the most cost effective option as they take time and labor to install. Again it’s always the best choice to consult with our skilled team as to what is the best screen choice for your event. Call us today and find out how we can help you find the best installation for your next event.







♦ Our advantages


Professional Manufacturer of led display

1. OEM service,No MOQ
2. Easy installation,regular items in Stocks
3. Offering free design drawing as requested.
4. Remote controlling and adjusting are available.
5. Wooden case or flight case,you are the boss.
6. Your reply will be replied within 24 hours.
7. Fast delivery: Usually 6-8 working days
8. Excellent R&D team,factory Price and assure you quality goods.

♦ Packaging and shipping

Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.

Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What's
more,unique standardized and module production ensure our products continuous quality.

Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.

Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.

Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we'll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.







Customer FAQ


1. How can I place an order?
Please provide all the details of your requirements for our reference So we can send you the offer at the first time.Feel free to contact with me by What's APP/email /phone to avoid any delay.

2. What kind of display we provide?
We have indoor/outdoor/LED stage/Sport display/ Irregular LED display/monitor screen for you choose.

3. Are you manufacturer of led display.If yes, in which city?
Yes, We already have more than 10 years experience for LED display as a LED manufacturer located in Shenzhen.

4. How long can I get the goods?
Our product leadtime is about 10-25 working days.When you confirm the order, we can start production at once receiving your deposit(30% TT in advance). we will update the production details in time.we will notice you when we can delivery the goods to you after we get full payment.

5. May I know the package details?
For fixed installation, we use wooden case, usually 2 or 4 cabinets in 1 wooden case;
For rental market, we suggest you use flight case, generally 8 cabinets in one flight case.
It's safe to protect the screen on the way, also economical.

6. What is the payment method?
We support the payment methods as TT, L/C.

7. What's the pixel pitch for Indoor LED Display Screen?
Indoor (P2.6mm/P2.97mm/P3.91/P4.81mm/P6.25mm) led display screen.

8. Can it play HD video?
Yes, it can realize HD video function with Linsn/nova controlling system.

9. What's the controlling system?
Our standard controlling system for this model is Linsn/ Novastar. Also support other controlling system, like Xixun,TF, Colorlight, etc.

10. What is your terms of delivery?
We accept EXW, FOB, CIF etc. You can choose the one which is the most convenient or cost effective for you.
