Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | P3.91 , P4.81 , P5.95 , P6.25 | Panel Dimension: | 500x500mm / 500x1000mm |
|---|---|---|---|
| IP Rating: | IP65/IP54 | Viewing Angle: | 160°（H）140°（V） |
| Sevicing: | Front / Rear | Brightness: | 6000 Nits |
| High Light: | events led display,led rental display |
||
Outdoor Rental LED Screen Flat and Curve Options with Reddot Awarded
Features:
1. Show the beauty
4000: 1 high contrast,160 ° viewing angle, support seamless splicing, high brush 1920Hz ,high gray 16bit.
2. LCD window monitoring founction
LCD monitoring screen to detect the exact temperature, voltage, working time, etc easily.
3. Outdoor Protection
IP65 front and IP54 rear to provide waterproof and dustproof operating environment..
4. Curved shape available
±10 ° angle lock for curved screen, 90° right angle cabient for cubic screen.
5. Die-casting Aluminum
Leasing LED video screen with die-casting aluminum frame design, screen is super light and thin, saving space and costs, fashionable and beautiful; Adopting die-casting aluminum improves the heat dispersion, prolonging the lifetime of the led display.
6. Slim and lightweight
Convenient in transporting and installing & saving labor cost, suitable for flow shows.
7. Dual signal backup port
Data backup ports on rear box for special situation.
Specification:
| BOR-I-3 | BOR-I-4 | BOR-I-5 | |
| Physical Pitch | 3.91mm | 4.81 mm | 5.95mm |
| Pixel Configuration | SMD 1921 | SMD 2525 | SMD 2525 |
| Pixel Density | 65,536 pixels/m² | 43,264 pixels/m² | 28,224pixels/m² |
| Module Dimensions (W × H) (mm) | 250 × 250 / 250×500 | 250 × 250 / 250×500 | 250 × 250 / 250×500 |
| Panel Dimensions (mm) | 500 × 500 × 80 | 500 × 500 × 80 | 500 × 500 × 80 |
| 500 × 1000 × 80 | 500 × 1000 × 80 | 500 × 1000 × 80 | |
| NO .of Modules Per Panel (W × H) | 2 × 2 | 2 × 2 | 2 × 2 |
| Physical Resolution of Module (W × H) | 64×64/64×128 | 52×52/52×104 | 42×42/42×84 |
| Physical Resolution of Panel (W × H) | 128×128/128×256 | 104×104/104×208 | 84×84/84×168 |
| Panel Material | Die-Casting Aluminum | Die-Casting Aluminum | Die-Casting Aluminum |
| Single Cabinet Weight | 9/ 15 kg/panel | 9/ 15 kg/panel | 9/ 15 kg/panel |
| Gray Scale | 14-16 bit | 14-16 bit | 14-16 bit |
| Colors | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 4,000: 1 | 4,000: 1 | 4,000: 1 |
| Average Power Consumption | 75 /150 W/m² | 75 /150 W/m² | 75 /150 W/m² |
| Max Power Consumption | 225 /550 W/m² | 225 /550 W/m²l | 225 /550 W/m² |
| Operating Temp/Humidity | -20ºC - 60ºC / 10% - 60% | -20ºC - 60ºC / 10% - 60% | -20ºC - 60ºC / 10% - 60% |
| Storage Temp/Humidity | -30ºC - 60ºC / 10% - 60% | -30ºC - 60ºC / 10% - 60% | -30ºC - 60ºC / 10% - 60% |
| Refresh Rate | >1,920 Hz | >1,920 Hz | >1,920 Hz |
| Brightness | >5000 nits | >5000 nits | >5000 nits |
| Horizontal Viewing Angle | 160° | 160° | 160° |
| Vertical Viewing angle | 140° | 140° | 140° |
| Expected Lifetime | 100, 000 Hrs | 100, 000 Hrs | 100, 000 Hrs |
| Max Stacking | 20/10 | 20/10 | 20/10 |
| Max Hanging | 20/10 | 20/10 | 20/10 |
| Servicing | Front / Rear | Front / Rear | Front / Rear |
| IP Rating (Front/Rear) | IP 65/ IP 54 | IP 65/ IP 54 | IP 65/ IP 54 |
| Scan Method | 1/16 Scan | 1/13 Scan | 1/7 Scan |
Solutions:
Company Introduction:
BAKO VISION started the business journey from 2005 in shenzhen and now become a professional LED display manufacturer.We were witnessed by customers from more than 100 countries and never stop our step to develope oversea market.
Now our company is equipped with eighteen automatic SMT lines and three DIP lines with high speed machines of Panasonic and Samsung,some of them for OEM customers and some for standard screen or large screen.We also owns experienced R & D team and comprehensive management.All of these are the factors enable us to provide advanced quality and service for our customers.
