Product Details:
Payment & Shipping Terms:
|
| Physical Pitch: | 3.91mm | Brightness: | >1200 Nits |
|---|---|---|---|
| Tube Chip Color: | Full Color | Led Chip: | Nation Star |
| Refresh Rate: | >1920 | Module Resolution: | 64*64 Dots |
| Contrast Ratio: | 4000:1 | Panel Material: | Die-casting Aluminum |
| High Light: | indoor full color led display,led publicity screens |
||
P3.91 Very Popular And High Definition Indoor Rental LED Display User Friendly
BIR-III Series
●Lightweight Large Format Cabinet
●Cabinet 500mmx500mm or 500mmx1000mm
●High Definition Indoor Display
●Curvilinear, Concave, Convex
Specification
| Physical Pitch | P3.91mm |
| Pixel Configuration | SMD 2121 |
| Pixel Density | 65,536px/m² |
| Module Dimensions(W*H)(mm) | 250*250 |
| Panel Dimensions(mm) | 500*500*80/500*1000*80 |
| NO. of Modules Per Panel (W*H) | 2*2/2*4 |
| Panel Material | Die-casting Aluminum |
| Colors | 281 trillion |
| Gray Scale | 16 bit |
| Pixel Failure | <0.0003 |
| Life Span | ≥50000 Hours |
| Viewing Angle(H/V) | 160°/140° |
| Operating Temp/Humidity |
-10℃-60℃/ 10%-60% |
| Storage Temp/Humidity |
-30℃-60℃/ 10%-60% |
| MTBF | ≥1000 Hours |
| Single Cabinet Weight | 8/14 kg/ panel |
| IP rating | IP40/ IP21 |
| Servicing | Front/Rear |
| Physical Resolution of Module(W*H)(mm) | 64*64 |
| Physical Resolution of Whole Set(W*H)(mm) | 128*128/128*256 |
| Average Power Consumption | 64/128 w/m2 |
| Refresh rate | ≥ 1920Hz |
| Contrast ratio | 4000:1 |
Unsurpassed Color Uniformity
Tight bin selection for LED wavelength
Deep black levels, contrast ratio 4000:1
Fast Installation and Easy Maintenance
Truss hanging and ground support both available
Cable-less between modules
Tools free installation
Slim, Light Weight and Quiet
80mm thickness, 7 KG per cabinet
Fanless design
High refresh rate
The vedio quality of indoor P3.91 LED display
Image quality is exquisite, nonlinear correction technology, graphics exquisite and clear; Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience to get short ROIof your LED display screen's investment.
Production Line
After sale service
Warranty
We guarantee all our displays, modules, parts for TWO years. During this time, we
will replace or amend all our goods for free if there is something wrong with them.We provide lifetime maintenance service and only charge for the cost of raw materials needed.We provide technology training for free, which contains operation and maintenance training of the LED screens in the factory.We also provide operation manual, software, test report and so on. Any associated CAD drawings on how to fix up the display. And some other expert suggestions will be provided for free.
