Product Details:
Payment & Shipping Terms:
|
| IP Rating: | IP65 | Weight: | 65kg/sqm |
|---|---|---|---|
| Gray Scale: | 16 Bit | Contrast Ratio: | 2000:1 |
| Refresh Rate: | ≥1920Hz | Panel Material: | Die-casting Aluminum |
| High Light: | street led screen,outdoor waterproof led advertising panels |
||
6500 Nits P4/P6/P8/P10 Outdoor Fixed Led Video Display for Commercial Ads Beside Highway
LED Display Features:
1. Super light design ensure the cabinet easy to be installed and disassembled
2. High brightness meet the needs of various application environments
3. Energy saveing design and good performance in color uniformity
4. Super workmanship to ensure every processing details
5. Environmental raw material (LED chips, mask, glue, and steel cabinets)
6. Large viewing angle. Horizontal:±120 ° , Vertical: ±120°
7. high reliablity: our outdoor fixed led display can work for at least 4-5 years, due to we use good parts, such as led, power supply, cables,etc.
Specifications of P4/P6/P8/P10 outdoor fixed led display
| Model | BOF-F-6 |
| Pixel Pitch | 6.67mm |
| Pixel Density | 22500 pixels/m2 |
| LED Type | SMD3535 |
| LED Configuration | 1R1G1B |
| Cabinet Dimension | 960mm*960mm |
| Cabinet Resolution | 144*144pixels |
| Weight | 65kg/sqm |
| Cabinet Material | Die-casting Aluminum |
| Ingress Protection | IP65/IP54 |
| (front/rear) | |
| Brightness | >6500nits |
| Viewing Angle(H/V) | 140°/140° |
| Driving Method | 1/6 scan |
| Frame Refresh | ≥ 60Hz |
| Data Refresh Rate | >1500Hz |
| Gray Scale | 16bit |
| Power Consumption(avg.) | 300w/m2 |
| Input Voltage | AC 110/220±10% |
| 50~60Hz | |
| Temperature | -20~50°C / -40~60°C |
| (operating/storage) | |
| Humidity(operating/storage) | 10%~90%RH |
| / 10%~85%RH | |
| MTBF | ≥1000hrs |
| Life Span | ≥100000hrs |
| Pixel Failure | <0.0003 |
Shenzhen BAKO VISION Technology Co., Ltd, started in Shenzhen in 2005,a world class manufacturer of
technologically advanced LED displays,it is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.
BAKO VISION product lines have include I/O rantal,I/O fixed, UHD fine pitch, transparent screen,advertising poster,foldable screen… meanwhile, based on our experienced R&D team,and comprehensive management , we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.
FAQ
Q1:How to choose a proper led screen for your need?
A:You just need to think of 3 simple questions when you choose a led screen by yourself.
1.Will you use it indoor or outdoor?
2.Is it for rental use(need to be moved from one place to another place very often) or for fixed installation(to be installed in one place forever)?
3.what is the appoximate size of the led screen you would like to purchase?
Q2:Which pixel pitch should i choose?
A:There are many different pixel pitch from 1.667--20,25,30mm, there is a roughly principle-usually small pixel(1.667mm-10mm) used for indoor led screen, bigger pixel (10mm-30mm) used for outdoor led screen(for example high way huge advertisement).
Q3:Which control system should i choose?
A:There is both synchronous and asynchronous control system for led screen on the market,for big size led screen(usually more than 20sqm) need to use synchronous control system,below 20sqm it's up to you to use syn or asyn.But asyn control system's refresh rate is much lower than sync control system and for asyn control system, you can choose to use wifi,3G,4G etc wireless control.
